$ 857.67
High-res 8 MP IDS GV-51J1ACP camera with Sony IMX546 sensor, global shutter, GigE interface, and C-Mount. Ideal for precision automation & inspection.
The IDS GV-51J1ACP series is a GigE Vision-compliant industrial camera built around the Sony IMX546 global shutter CMOS sensor, offering 8.13 MP resolution (2856 x 2848 px) in a compact, lightweight form. Available in both Color (C-HQ) and Mono (M-GL) variants, this camera line is tailored for applications requiring low-noise performance, precise synchronization, and long-term availability for industrial integration.
Engineered for advanced machine vision needs, the GV-51J1ACP camera series addresses the demand for high-resolution image acquisition with true global shutter performance, even under fast motion or variable lighting. The C-Mount lens interface, 128 MB onboard memory, and high-speed 12-bit ADC ensure flexibility and accuracy in optical inspection, robotics, and factory automation tasks. The GV-51J1ACP-M-GL (mono) version is optimized for intensity-based measurements, while the GV-51J1ACP-C-HQ (color) supports vibrant true-color applications.
With long exposure capability up to 120 seconds, integrated LUT, PTP, and GPIOs for strobe/trigger control, this series empowers engineers in industries like semiconductor inspection, precision assembly, and scientific imaging to build reliable, synchronized vision systems.
| Feature | Details | Benefit |
|---|---|---|
| Sensor Brand & Model | Sony IMX546 (Color: AAQJ-C / Mono: AAMJ-C) | High-sensitivity, global shutter CMOS sensor |
| Interface | GigE Vision (RJ45 via breakout) | Long cable runs and standardized communication |
| Interface Speed | 1 Gbps | Stable transfer even for large image sizes |
| Resolution (HxV) | 2856 x 2848 (8.13 MP) | Square format ideal for flexible image framing |
| Optical Area (HxV) | 7.825 mm × 7.804 mm | Broad light capture for enhanced sensitivity |
| Optical Format | 1/1.45″ (Diagonal 11.07 mm) | Matches many high-quality C-Mount lenses |
| Lens Mount | C-Mount | Compatible with industrial lenses |
| Pixel Size | 2.74 µm | Fine detail capture and enhanced spatial resolution |
| Image Memory | 128 MB | Supports frame buffering and multi-camera setups |
| Frame Rate @ Max Resolution | 15 fps (16 fps with trigger) | Real-time capture with trigger synchronization |
| Shutter | Global Shutter | Motion-freeze accuracy for fast-moving subjects |
| Exposure Time | 0.064 ms to 120000 ms | Ranges from high-speed imaging to ultra-long exposure |
| Power Consumption | 1.6 W – 4.2 W | Efficient design for embedded system use |
| Dimensions (HxWxL) | 84 × 40 × 29.7 mm | Space-saving form for integration into compact systems |
| Weight | 34 g | Lightweight housing for robotic and mobile applications |
| Ambient Operating Temp | 0°C to 55°C | Stable performance in demanding environments |
| Image Formats (Color) | BayerRG8/10/12, RGB8/10p32, BGR8/10p32 | Flexible for vibrant color representation |
| Image Formats (Mono) | Mono8/10/12, Mono10p/12p | Enhanced grayscale fidelity and low-light sensitivity |
| Advanced Features | Auto Exposure/Gain, LUT, ROI, Sequencer, Flash | Onboard processing & precise control for complex vision applications |
Machine Vision Engineers: Ideal for high-precision measurement and inspection tasks that require low-noise, square-format imaging.
Automation Integrators: Easily integrated into GigE-based systems, especially those involving synchronized imaging or robotics.
Researchers & OEMs: Long-term product availability ensures lifecycle stability for scientific or volume production environments.
Developers of Embedded Vision Systems: Compact, low-power, and equipped with versatile I/O for triggers, flashes, and GPIOs.
This camera resolves key challenges in motion blur, color accuracy, and limited integration space. By combining global shutter, high resolution, and versatile hardware I/O in a small form factor, it delivers performance where rolling shutter or bulky systems would fail. It’s the go-to for industrial projects needing precision, repeatability, and future-proofing.
As an authorized distributor of IDS Imaging products, we offer certified expertise and technical support to ensure you get the most out of your IDS GV-51J1ACP camera. We stand by the quality of our products and provide comprehensive warranty services. Our team can also assist with special services like custom integration and creating pre-configured kits tailored to your specific needs.
We also offer:
Custom integration services for embedded systems
Pre-configured vision kits tailored to your project requirements
IDS Accessories (Recommended):
C-Mount Lenses (IDS Approved) – Optimized for 1/1.45″ sensors
GigE Hubs and Cables – For multi-camera GigE setups
GPIO Interface Boards – Enables trigger, flash, and LED synchronization
Heat Sinks or Mounting Brackets – For thermal and mechanical integration
