Why HTB18L-P1G5BB?
The HTB18L-P1G5BB is chosen for its precise laser detection, compact M18 form, and ability to identify even small or low-contrast objects with remarkable consistency. It blends speed, accuracy, and rugged durability, making it ideal for modern automated lines that need stable performance without constant recalibration or fine-tuning.
What Problem Does It Solve?
The HTB18L-P1G5BB eliminates unreliable detection caused by color variations, shiny surfaces, or changing background conditions. It solves the challenge of maintaining accurate object presence sensing in fast-moving or space-limited environments, ensuring automation flows smoothly without miscounts, false triggers, or production stops.
Key Features & Specifications – SICK HTB18L-P1G5BB: Part Number 1074785
| Feature | Details | Benefit |
|---|---|---|
| Detection Technology | Laser background suppression | Stable sensing even with color or surface variation |
| Light Source | Class 1 visible red laser, 655 nm | Safe, precise, and easy-to-align light spot |
| Sensing Range | 30–250 mm (max 300 mm depending on target) | Flexible detection distance for various setups |
| Light Spot Size | 2 mm at 120 mm distance | Detects small or narrow objects accurately |
| Response Time | ≤ 0.5 ms | Enables tracking of high-speed moving parts |
| Switching Output | Dual PNP, complementary (Light & Dark switching) | Easy integration into control systems |
| Switching Frequency | 1,000 Hz | Ideal for fast-paced automation lines |
| Signal Strength Indicator | Multi-segment light bar | Simplifies setup & quick diagnostics |
| Adjustment Method | Potentiometer for sensing range | Fine-tuned configuration for precision detection |
| Housing Type | M18 hybrid, blue VISTAL® | Strong, lightweight housing for industrial use |
| Protection Rating | IP67 & IP69K | Withstands washdown, dust, moisture & harsh environments |
| Operating Temperature | –30 °C to +55 °C | Suitable for cold-storage to warm factory floors |
| Connection | 2 m PVC cable, 4-wire | Durable cabling ready for direct wiring |
| Current Consumption | ≤ 20 mA | Energy-efficient operation |
| Output Current | ≤ 100 mA | Supports a range of industrial loads |
| Materials | Optics: PMMA, Housing: VISTAL® | High resistance to chemicals, impact & wear |
| Mounting System | M18 thread, side & head mounting supported | Fits into constrained or flexible installation layouts |
| Special Feature | Detects small objects with high stability | Ideal for packaging, assembly & electronics handling |
| Certifications | CE, UL, UKCA, cULus | Meets international compliance requirements |
Download SICK HTB18L-P1G5BB (1074785) Datasheet
Commercial Information – SICK HTB18L-P1G5BB
| Commercial Data | Details |
|---|---|
| EAN Number | 4047084373374 |
| Weight | 101 g |
| Country of Origin | United States |
