SICK HTB18L-N3A5AB Laser Photoelectric Sensor

SICK HTB18L-N3A5AB Laser Photoelectric Sensor with Background Suppression

The SICK HTB18L-N3A5AB photoelectric sensor is engineered for accurate object detection where stability and precision are critical. Using a focused red laser and a compact M18 housing, it delivers consistent performance across a 30–250 mm working range, even when objects vary in color, reflectivity, or texture. Designed for modern automation environments, it reacts in just 0.5 ms, making it suitable for high-speed lines and tight installation spaces. With its durable construction and high ingress protection, the sensor maintains reliable performance in demanding industrial conditions.

The HTB18L-N3A5AB provides dependable detection of small or visually inconsistent targets by combining laser accuracy with stable background filtering. Its dual NPN switching outputs allow users to configure detection logic according to system requirements, while the compact 4-pin M8 connection supports quick installation and maintenance. Built from impact-resistant materials and sealed to withstand washdown environments, it offers long service life in applications such as packaging machinery, robotic pick-and-place, parts verification, and object counting. The sensor minimizes false triggers and increases process consistency, helping facilities improve uptime and reduce quality-related losses.

Why HTB18L-N3A5AB?

The HTB18L-N3A5AB stands out for its laser-sharp accuracy, compact M18 design, and ability to detect objects that other sensors struggle with. It delivers stable results even when colors or surfaces change, making it a powerful upgrade for any automation line seeking higher precision, fewer errors, and long-term reliability in tough industrial environments.

What Problem Does It Solve?

This sensor eliminates inconsistent detection caused by shiny, dark, or low-contrast materials that usually confuse standard photoelectric sensors. By maintaining reliable background suppression and ultra-fast response, it prevents false triggers, missed counts, and production interruptions—ensuring smoother operations, better quality control, and dependable performance even at high speeds.

Key Features & Specifications – SICK HTB18L-N3A5AB : Article Number 1071033

Download SICK HTB18L-N3A5AB (1071033) Datasheet

Commercial Information – SICK HTB18L-N3A5AB

The Applications

1. High-Speed Packaging Presence Detection

Modern packaging lines move quickly, and each product must be confirmed before sealing, printing, or boxing. The HTB18L-N3A5AB is well-suited for this task because its laser spot can reliably detect items with inconsistent colors or reflective finishes. Even slim or irregular shapes are identified without being influenced by conveyor surfaces or nearby machinery. When placed before key stations, the sensor ensures that only correctly positioned products advance, reducing wasted film, incorrect labeling, and downtime caused by empty packs. Its rapid reaction time keeps pace with high-cycle operations, supporting smoother transitions between processing stages and improving overall line efficiency.

2. Robotic Pick-and-Place Position Confirmation

Robotic systems depend on accurate part detection to coordinate gripping and placement. The HTB18L-N3A5AB offers the precision needed to detect small or low-contrast components that may be difficult for conventional sensors to recognize. Its focused laser beam helps the robot verify that a component is ready to be picked, even when surfaces are polished, dark, or irregular. By providing consistent triggers, the sensor reduces missed picks, prevents collisions, and maintains smoother robot motion. This stability is especially valuable in compact work cells where space is tight and the timing between detection and movement must remain highly predictable for maximum throughput.

3. Electronics Assembly Component Verification

In electronics production, small connectors, housings, and fittings must be confirmed before further assembly. The HTB18L-N3A5AB excels in this environment because its narrow laser spot can detect tiny parts and distinguish them from reflective work surfaces. When installed above assembly nests, it instantly indicates whether a part is missing or incorrectly positioned. This early feedback prevents faulty assemblies before they reach soldering or enclosure steps. The sensor’s stability also helps maintain consistent inspection criteria across multiple workstations, supporting higher production quality and reducing manual checks that would otherwise slow down the process.

4. Bottle Detection on Beverage Processing Lines

Bottling operations often work with transparent, tinted, or dark containers, each presenting different detection challenges. The HTB18L-N3A5AB handles these variations effectively due to its precise laser and controlled background suppression. Positioned at infeed points of filling or capping stations, it confirms that a bottle is correctly present before the next action occurs. This prevents filler nozzles from dispensing without a container beneath them and avoids mechanical interference during capping. Its fast switching capability keeps up with rapid conveyor speeds, helping production maintain consistent throughput while reducing product loss and unnecessary machine stops.
