Why SICK GRSE18S-P1336?
Choose the SICK GRSE18S-P1336 for its exceptional detection accuracy, long 15 m sensing range, and rugged IP67 housing. Its precise red PinPoint LED ensures easy alignment, while the high-speed 500 µs response captures even fast-moving targets. Designed for reliability, it’s the ideal balance of precision, speed, and durability in demanding industrial environments.
What Problem Does It Solve?
The GRSE18S-P1336 eliminates false detections and missed readings in complex automation setups. It tackles challenges like inconsistent object positioning, dust interference, and limited visibility by delivering sharp, consistent detection performance. This ensures smoother operation, reduced downtime, and improved product flow across conveyors, robotic arms, and packaging machinery.
Key Features & Specifications – SICK GRSE18S-P1336 (Article No. 1059545)
| Feature | Details | Benefit |
|---|---|---|
| Functional Principle | Through-beam photoelectric sensor | Reliable long-range detection up to 15 meters with high accuracy. |
| Sensing Range | 0 to 15 m (typical 10 m) | Suitable for wide detection applications and long conveyor systems. |
| Light Source | Visible red PinPoint LED, 650 nm | Sharp, focused light for easy alignment and high repeatability. |
| Response Time | < 500 µs | Captures fast-moving objects with minimal latency. |
| Switching Frequency | 1,000 Hz | Ensures consistent and rapid signal processing in automation. |
| Output Type | PNP, Light Switching | Easy integration with industrial control systems and PLCs. |
| Supply Voltage | 10–30 V DC | Flexible use across various industrial power configurations. |
| Current Consumption | ≤ 30 mA | Energy-efficient operation for continuous usage. |
| Output Current | ≤ 100 mA | Stable output for reliable control signal transmission. |
| Housing Design | Cylindrical M18 × 1, axial optics | Compact, space-saving design for flexible installation. |
| Housing Material | ABS (Plastic) | Lightweight and durable for industrial environments. |
| Optics Material | PMMA (Acrylic) | Scratch-resistant lens for long-lasting clarity. |
| Enclosure Rating | IP67 | Protection against dust and water for harsh operating conditions. |
| Operating Temperature | –25°C to +55°C | Reliable performance in diverse ambient conditions. |
| Connection Type | 3-wire, 2 m PVC cable | Quick installation and secure electrical connection. |
| Status Indicators | Green (Power), Yellow (Beam Status) | Simplifies troubleshooting and system monitoring. |
| Certifications | CE, cULus, ECOLAB, UKCA, China-RoHS | Global compliance for multi-region deployment. |
Download SICK GRSE18S-P1336 (1059545) Datasheet
Commercial Information – SICK GRSE18S-P1336 (Article No. 1059545)
| Commercial Data | Details |
|---|---|
| EAN Number | 4047084303043 |
| Weight | 90.3 g |
| Country of Origin | Malaysia |
The Applications
1. Automated Conveyor Parcel Sorting
In a busy logistics center, parcels of different sizes move rapidly along conveyor belts. A through-beam sensor positioned across the line detects each package as it interrupts the light beam. The SICK GRSE18S-P1336 with its 15 m sensing range and high-speed response ensures every item is counted accurately, even in high-throughput systems. The PinPoint red LED helps technicians align the beam quickly across long spans, while built-in electrical protection ensures dependable operation amid strong electrical noise from other equipment.
2. Bottle Labeling and Fill Level Verification
In a beverage production facility, bottles pass at high speed through filling and labeling stations. The GRSE18S-P1336 detects clear or reflective containers that other sensors might miss. Its through-beam detection provides precise, stable readings for correct label placement and fill verification. The IP67-rated housing prevents damage from water or cleaning sprays, ensuring consistent accuracy without frequent recalibration. Its compact size also fits neatly into tight production lines, maintaining efficiency without sacrificing reliability.
3. Sheet Metal Edge Detection in Press Lines
During metal forming operations, the correct positioning of sheet metal is vital. The GRSE18S-P1336 detects the leading edge of each sheet as it moves into a press, preventing jams and costly misfeeds. With its 500 µs response time and strong optical beam, it tracks fast-moving materials even under intense vibration and ambient light. The rugged ABS housing and over-current protection ensure dependable performance in heavy-duty industrial environments where precision timing and reliability are critical.
4. Safety Gate and Access Barrier Monitoring
In robotic or automated production areas, maintaining operator safety is essential. The GRSE18S-P1336 acts as a monitoring sensor for gates or access barriers—stopping machines the instant its beam is interrupted. The long sensing distance allows it to cover wide entry zones, while its visible LED simplifies setup and maintenance checks. With IP67 sealing and resistance to dust and oil, it continues to perform flawlessly in harsh factory environments, ensuring reliable protection without unnecessary downtime.
Related Products & Accessories – SICK GRSE18S-P1336 (GR18 Series)
| Category | Model Name | Part Number | Benefits |
|---|---|---|---|
| Emitter (Transmitter Unit) | SICK GRS18S-D1336 | 2065196 | Pairs perfectly with GRSE18S-P1336 for reliable through-beam detection up to 15 m; provides stable and precise light output. |
| Receiver (Sensor Unit) | SICK GRSE18S-P1336 | 1059545 | Detects beam interruption accurately with high-speed response; delivers dependable object detection in automation lines. |
| Alternative Receiver Model | SICK GRE18S-P1336 | 2065199 | Compatible design within the GR18 series; ideal for system standardization or spare part replacement. |
| Mounting Bracket | SICK BEF-WN-M18 | 5308446 | Zinc-coated steel bracket for secure M18 mounting; allows easy adjustment and alignment of sensor positions. |
| Connection Cable | SICK STE-0803-G | 6037322 | 3-pin M8 straight connector ensures quick, reliable wiring; compatible with PNP output sensors for plug-and-play setup. |
