1. Industrial Control Panel Grounding
Used in industrial control panels to establish a reliable and secure protective earth (PE) connection for various electrical components and machinery.
Problem SolvedEnsures personnel safety and equipment protection by providing a robust grounding path for large cross-section conductors (up to 35 mm² / 2 AWG), preventing electrical shock and equipment damage in high-current industrial environments. Its CAGE CLAMP® technology provides vibration-proof connections crucial in factory settings.
Protective EarthControl PanelHigh Current GroundingCAGE CLAMPDIN Rail MountVibration-proof
2. Building Electrical System Grounding
Implemented in commercial and industrial building electrical systems for grounding main distribution boards or sub-panels, connecting heavy-gauge grounding conductors.
Problem SolvedFacilitates safe and compliant grounding of significant electrical infrastructure, accommodating large conductor sizes (6 mm² to 35 mm²). The green-yellow color coding ensures clear identification of the ground connection, meeting electrical code requirements for safety and preventing miswiring.
Main Distribution BoardElectrical InfrastructureBuilding CodesGrounding ConductorElectrical SafetyLarge Wire Gauge
3. Renewable Energy System Earthing
Utilized in solar power installations or wind turbine control cabinets for earthing and surge protection devices, connecting ground lines from solar arrays or wind generators to the system's earthing grid.
Problem SolvedProvides a dependable and sturdy earthing point for high-power renewable energy systems, which often require robust grounding for lightning protection and fault current dissipation. Its operating temperature range (-35 to 85 °C) supports outdoor cabinet applications where temperature fluctuations are common, while CAGE CLAMP® ensures reliability in harsh conditions.
Renewable EnergySolar PVWind TurbineEarthing GridSurge ProtectionHarsh EnvironmentTemperature Resistance
