1. 6-Axis Robotic End-Effector Vision System for Automotive Assembly
Utilized in heavy industrial automotive lines where a USB 3 uEye CP Rev.2.2 camera is mounted on the end-effector of a large 6-axis robotic arm for automated welding inspection. The cable routes from the moving robot wrist, through the arm's internal channels, to an industrial PC situated safely outside the work cell.
Problem SolvedStandard copper cables degrade and snap under constant multi-directional twisting, and their data signals drop over long spans. This hybrid AOC maintains high-bandwidth USB 3 vision data over a 10.0 m cable length without repeaters. Its torsion rating of min. 4.5 million cycles prevents mechanical failure from the robot's complex rotations, while the USB-C metal jack screwable connectors ensure the high vibrations of the robot arm do not dislodge the connection.
Torsion min. 4.5 million cycles10.0 m Cable lengthUSB-C metal jack screwableUSB 3 uEye CP Rev.2.2
2. High-Speed Gantry Pick-and-Place Optical Sorting Machine
Deployed in high-speed pharmaceutical and electronics sorting equipment, connecting overhead gantry cameras (like the USB 3 uEye SE) to a centralized vision controller. The cable is housed inside flexible energy chains (drag chains) that rapidly traverse the X and Y axes across large conveyor beds.
Problem SolvedIn gantry systems, powerful electrical servo motors often generate massive electromagnetic interference (EMI) that corrupts copper USB lines. The Hybrid AOC (glass fiber optic) design ensures complete EMI immunity. Additionally, the cable survives continuous linear, back-and-forth motion without internal wire fatigue, justified by its mechanical rating of min. 500,000 bending cycles and a safe 40.0 mm bending radius.
Bending cycles min. 500,000 cyclesBending radius 40.0 mmHybrid AOC (glass fiber optic)USB 3 uEye SE
3. Telescoping Mast Vision on Automated Guided Vehicles (AGVs)
Integrated into mobile autonomous inspection robots operating in large warehousing or aerospace manufacturing environments. A lightweight USB 3 uEye XLE camera is mounted atop a tall, extendable mechanical mast, capturing high-resolution 3D point clouds and routing the data back to the vehicle's base processor.
Problem SolvedRouting data down an extendable boom requires a long, flexible, and rugged connection. The 10.0 m cable length accommodates the fully extended distance without latency or signal drops. Furthermore, AGVs navigating over uneven factory floors experience heavy mechanical shocks. The screw-in locking mechanism (Screw-in: Yes) on both connectors prevents accidental disconnections, ensuring the vision system remains online during mobile transit.
Cable length 10.0 mscrew-in YesUSB 3USB 3 uEye XLE
