UC4-13347 Ultrasonic sensors – SICK Sensor

Name: UC4-13347 Ultrasonic sensors - SICK Sensor - INOSAKI
SKU: SICK-6054709
Price: 423.54 USD
Availability: InStock

$ 423.54

Optimize your automation with the SICK UC4-13347 (6054709). This compact ultrasonic sensor offers a 20-150mm range, 0-10V analog output, and IP67 protection.

SKU SICK-6054709 Category Ultrasonic Distance Sensors - SICK UC4

Product Overview

Model Name: UC4-13347
Part Number: 6054709
Sensor Type: Ultrasonic distance sensor
Operating Range: 20 mm to 150 mm (Limiting range up to 250 mm)
Output Type: Analog voltage output (0 V … 10 V)
Connection: Male connector, M8, 3-pin
Housing Material: Plastic (ABS) with ultrasonic transducer (polyurethane foam/glass epoxy resin)
Supply Voltage: DC 15 V to 30 V

Product Description

The SICK UC4-13347 (6054709) is a high-precision ultrasonic distance sensor designed for industrial automation where space is at a premium and reliability is non-negotiable. As part of the UC4 product family, it utilizes advanced ultrasonic technology to detect objects regardless of color, transparency, or surface gloss. This makes it an ideal alternative to optical sensors in challenging environments containing dust, dirt, or fog.

Measuring just 16 mm x 40.1 mm x 16.7 mm, its ultra-compact rectangular housing allows for seamless integration into small machines and tight assembly lines. The sensor provides a linear 0 V to 10 V analog signal, delivering precise distance information with a resolution of ≥ 0.1 mm and a repeatability of ± 0.15%. With integrated temperature compensation and an IP67 enclosure rating, the UC4-13347 ensures stable performance even under fluctuating thermal conditions and exposure to moisture. Its simple teach-in process and “Object between sensor and background” (ObSB) mode allow for rapid configuration and maximum operational flexibility in high-speed production environments.

Key Performance Features

Material Independence: Reliable detection of transparent, dark, shiny, and multi-colored objects.
High Precision: Excellent resolution of ≥ 0.1 mm and measurement accuracy of ± 1%.
Rapid Response: Fast response time of 24 ms for high-speed application requirements.
Smart Functions: Adjustable operating modes including Switching Point (DtO), Window Mode, and Background (ObSB).
Rugged Design: IP65/IP67 enclosure rating and a wide operating temperature range from –25 °C to +70 °C.
Temperature Compensation: Internal circuitry adjusts for temperature variations to maintain measurement stability.

Ideal Applications

Level Monitoring: Small container and vial level sensing in pharmaceutical or chemical industries.
Diameter Control: Monitoring the winding and unwinding of foils, paper, or wire on small reels.
Clear Object Detection: Detecting transparent glass, plastic bottles, or film on packaging lines.
Positioning: Precise positioning of robotic arms or small mechanical components in assembly.
Presence Detection: Checking for the presence of irregularly shaped components in electronics manufacturing.

Mechanics/electronics

Supply voltage V_s	DC 15 V … 30 V ¹⁾
Power consumption	≤ 0.75 W ²⁾
Initialization time	< 300 ms
Design	Rectangular
Housing material	Plastic (ABS) Ultrasonic transducer: polyurethane foam, glass epoxy resin
Connection type	Male connector, M8, 3-pin
Indication	2 x LED
Weight	10 g
Sending axis	Straight
Dimensions (W x H x D)	16 mm x 40.1 mm x 16.7 mm
Enclosure rating	IP65 / IP67
Protection class	III

¹⁾ Limit values, reverse-polarity protected, operation in short-circuit protected network: max. 8 A.
²⁾ Without load.

Performance

Operating range, limiting range	20 mm … 150 mm, 250 mm ¹⁾
Target	Natural objects
Resolution	≥ 0.1 mm
Repeatability	± 0.15 % ²⁾
Accuracy	± 1 % ³⁾
Temperature compensation	✔
Response time	24 ms ⁴⁾
Output time	8 ms
Ultrasonic frequency (typical)	380 kHz
Detection area (typical)	See diagrams
Additional function	Adjustable operating modes: Switching point (DtO) / Switching window/Background (ObSB), teach-in of digital output, invertable digital output, teach-in button(s) (can be deactivated), reset to factory default ⁵⁾

¹⁾ Teach-in from 21 mm.
²⁾ In relation to the current measured value, minimum value ≥ resolution.
³⁾ Referring to current measurement value.
⁴⁾ Subsequent smoothing of the analog output, depending on the application, may increase the response time by up to 200 %.
⁵⁾ Functions may vary depending on sensor type.

Interfaces

Analog output
Number	1
Type	Voltage output
Voltage	0 V … 10 V, ≥ 100,000 Ω
Resolution	12 bit

Ambient data

Ambient temperature, operation	–25 °C … +70 °C ¹⁾
Ambient temperature, storage	–40 °C … +85 °C

¹⁾ At operating temperatures of > 50 °C, the rear side of the UC4 must be installed with its surface flat against a bracket.
