Name: TP-Link TL-SH5654F L3 Managed Fiber Switch - INOSAKI
SKU: TP-Link-TL-SH5654F
Price: 2369.90 USD
Availability: InStock

Technical Overview

Layer 3 managed switch with 48 Gigabit SFP optical ports and 6 10G SFP+ uplinks. Supports RIP, static routing, advanced ACL/QoS, and remote cloud management.

Key Features

48 Gigabit SFP optical access ports for flexible, high-density fiber-optic networking
6 10-Gigabit SFP+ uplink ports enabling high-bandwidth aggregation and core connectivity
Robust Layer 3 capability supporting static routing, RIP dynamic routing, DHCP Server, and DHCP Relay
Comprehensive security suites including IP-MAC-Port-VLAN binding, ARP protection, IP Source Guard, and DoS defense
Advanced traffic management via standard 802.1Q VLAN, Private VLAN, QinQ (VLAN VPN), and granular QoS scheduling (SP, WRR, SP+WRR)
Versatile management tools including CLI, Web UI, SNMP (v1/v2/v3), RMON, LLDP, and TP-Link Commercial Cloud Platform integration

Technical Specification Matrix

Parameter	Value
Gigabit SFP Ports	48
10-Gigabit SFP+ Ports	6
Console Port	1 RJ45 Console Port
Input Voltage	100–240 V AC, 50/60 Hz
Maximum Power Consumption	71 W
Static Power Consumption	30 W
Form Factor	Rackmount, 1U
Operating Temperature	0℃ to 40℃
Storage Temperature	-40℃ to 70℃
Operating Humidity	10% to 90% RH (non-condensing)
Storage Humidity	5% to 90% RH (non-condensing)
Layer 3 Routing	RIP Dynamic Routing, Static Routing, DHCP Server, DHCP Relay, Proxy ARP
VLAN Features	IEEE 802.1Q VLAN, MAC VLAN, Protocol VLAN, Private VLAN, GVRP, VLAN VPN (QinQ)
Security Mechanisms	IP-MAC-Port-VLAN Binding, ARP Protection, IP Source Guard, DoS Protection, 802.1X, Port Security, DHCP Snooping
Spanning Tree Protocol	STP/RSTP/MSTP
Management Methods	Web UI, CLI (Console, Telnet), SNMP v1/v2/v3, RMON, LLDP, TP-Link Commercial Cloud Platform
Physical Weight (kg)	3
Dimensions L x W x H (cm)	22 x 44 x 4.4

Industrial Applications

1. Campus-Wide Optical Aggregation

Standard industrial or academic campuses require a central aggregation layer that connects multiple scattered sub-buildings or shop floors over long distances where copper cabling is limited. The 48 Gigabit SFP optical slots allow direct, noise-immune single-mode or multi-mode fiber runs from remote edge switches, avoiding electromagnetic interference in factory-adjacent environments.

Problem Solved

Bypasses the 100m copper limit and industrial EMI issues by aggregating 48 separate fiber optic links back to the core network over long distances.

Fiber-Optic AggregationSFP PortsLayer 3 AggregationEMI ImmunityGigabit SFP

2. Distributed Industrial Video Surveillance Network Aggregation

High-definition surveillance in sprawling industrial yards or mines generates massive bandwidth demand. The TL-SH5654F utilizes its 6 10-Gigabit SFP+ uplink ports to deliver non-blocking 10G high-bandwidth backbone transmission to central storage servers, while its 48 Gigabit SFP ports interface directly with fiber-optic field transceivers connecting high-resolution IP cameras across wide spatial footprints.

Problem Solved

Resolves bandwidth bottlenecks and frame drops by aggregating high-definition IP camera traffic over a 10G non-blocking backbone.

10G UplinkNon-Blocking Line RateIGMP SnoopingVideo AggregationSFP+ Slots

3. Multi-Subnet Segmented Process Control Networks

In automated facilities, separating administrative traffic from critical real-time SCADA or process control networks is essential for safety and performance. This Layer 3 switch implements RIP dynamic routing and static routing alongside private VLAN structures to isolate traffic subnets directly at the aggregation layer, allowing controlled, hardware-accelerated inter-VLAN routing without relying on a bottlenecked external router.

Problem Solved

Eliminates security exposure and router bottlenecks by hosting high-speed inter-VLAN routing and subnet isolation on-device.

Layer 3 RoutingRIPVLAN SegmentationACL SecurityInter-VLAN Routing
