| Input Number of Phases | 3 AC |
| Input Line Voltage | 380 ... 480 V +10% -20% |
| Input Line Frequency | 47 ... 63 Hz |
| Input Rated Current (LO) | 7.40 A |
| Input Rated Current (HO) | 6.00 A |
| Output Number of Phases | 3 AC |
| Output Rated Voltage (IEC) | 400V |
| Output Rated Voltage (NEC) | 480V |
| Output Rated Power (LO) | 2.20 kW (3.00 hp) |
| Output Rated Power (HO) | 1.50 kW (2.00 hp) |
| Output Rated Current (LO) | 5.60 A |
| Output Rated Current (HO) | 4.10 A |
| Output Rated Current (IN) | 5.80 A |
| Output Max. Output Current | 8.20 A |
| Output Pulse Frequency | 4 kHz |
| Output Frequency for Vector Control | 0 ... 240 Hz |
| Output Frequency for V/f Control | 0 ... 550 Hz |
| Overload Capability (Low Overload LO) | 150% base load current IL for 3s, then 110% IL for 57s in a 300s cycle time |
| Overload Capability (High Overload HO) | 200% base load current IH for 3s, then 150% IH for 57s in a 300s cycle time |
| Power Factor "λ" | 0.70 ... 0.85 |
| Offset Factor cos φ | 0.95 |
| Efficiency ":η" | 0.97 |
| Sound Pressure Level (1m) | 49 dB |
| Power Loss | 73.4 W |
| Filter Class (integrated) | Unfiltered |
| Communication Interface | PROFIBUS DP |
| Standard Digital Inputs Number | 6 |
| Standard Digital Inputs Switching Level (0→1) | 11 V |
| Standard Digital Inputs Switching Level (1→0) | 5 V |
| Standard Digital Inputs Max. Inrush Current | 15 mA |
| Fail-safe Digital Inputs Number | 1 |
| Digital Outputs (Relay Changeover Contact) | 1 |
| Digital Output (Relay Resistive Load) | DC 30 V, 0.5 A |
| Digital Outputs (Transistor) | 1 |
| Digital Output (Transistor Resistive Load) | DC 30 V, 0.5 A |
| Analog/Digital Inputs Number | 1 (Differential input) |
| Analog/Digital Inputs Resolution | 10 bit |
| Switching Threshold as Digital Input (0→1) | 4 V |
| Switching Threshold as Digital Input (1→0) | 1.6 V |
| Analog Outputs Number | 1 (Non-isolated output) |
| PTC/KTY Interface | 1 motor temperature sensor input (PTC, KTY, Thermo-Click), accuracy ±5 °C |
| V/f Control (Linear/Square-law/Parameterizable) | Yes |
| V/f with Flux Current Control (FCC) | Yes |
| V/f ECO Linear/Square-law Control | Yes |
| Sensorless Vector Control | Yes |
| Vector Control, with Sensor | No |
| Encoderless Torque Control | No |
| Torque Control, with Encoder | No |
| Cooling Method | Air cooling using an integrated fan |
| Cooling Air Requirement | 0.005 m³/s (0.177 ft³/s) |
| Installation Altitude | 1,000 m (3,280.84 ft) |
| Operating Temperature | -10 ... 40 °C (14 ... 104 °F) |
| Transport Temperature | -40 ... 70 °C (-40 ... 158 °F) |
| Storage Temperature | -25 ... 55 °C (-13 ... 131 °F) |
| Max. Operating Humidity | 95% at 40 °C (104 °F), non-condensing and no icing |
| Signal Cable Conductor Cross-section | 0.15 ... 1.50 mm² (AWG 24 ... AWG 16) |
| Line Side Connection Version | Plug-in screw terminals |
| Line Side Conductor Cross-section | 1.00 ... 2.50 mm² (AWG 18 ... AWG 14) |
| Motor End Connection Version | Plug-in screw terminals |
| Motor End Conductor Cross-section | 1.00 ... 2.50 mm² (AWG 18 ... AWG 14) |
| DC Link (for Braking Resistor) Connection Version | Plug-in screw terminals |
| DC Link (for Braking Resistor) Conductor Cross-section | 1.00 ... 2.50 mm² (AWG 18 ... AWG 14) |
| DC Link Line Length, Max. | 15 m (49.21 ft) |
| PE Connection | On housing with M4 screw |
| Max. Motor Cable Length (Shielded) | 150 m (492.13 ft) |
| Max. Motor Cable Length (Unshielded) | 150 m (492.13 ft) |
| Degree of Protection | IP20 / UL open type |
| Frame Size | FSAA |
| Compliance with Standards | CE, cUL, UL, KC, EAC, C-Tick (RCM) |
| CE Marking Directives | EMC Directive 2004/108/EC, Low-Voltage Directive 2006/95/EC |
| Converter Efficiency Class | IE2 |
| Physical Weight (kg) | 1.1 |
| Dimensions L x W x H (cm) | 22.5 x 27 x 8.5 |
