$ 251.85
Compact SICK RFH510-1004301 RFID reader with IO-Link for precise short-range identification. Ideal for industrial automation and traceability systems.
The SICK RFH510-1004301 RFID reader is a compact, high-frequency (13.56 MHz) short-range device built for precise object identification in demanding industrial environments. It features an integrated antenna and a robust IP67-rated housing, ensuring dependable operation in areas exposed to dust, vibration, or moisture. Supporting ISO/IEC 15693 and ISO/IEC 18000-3 Mode 1 standards, it provides accurate tag detection within a range of up to 60 mm. With its IO-Link interface, the RFH510 enables efficient data communication, improving process reliability and traceability across production, logistics, and equipment tracking systems.
The RFH510-1004301 combines durable mechanical design with intelligent communication for advanced industrial RFID applications. It offers real-time parameterization and diagnostics through IO-Link V1.1, simplifying device integration and maintenance. Multi-color status LEDs give instant feedback during setup and operation, minimizing configuration time. Its low power consumption and long mean time to failure make it an energy-efficient and maintenance-free choice. Ideal for automated manufacturing lines, assembly monitoring, and tool identification, this RFID reader enhances transparency and quality control by delivering consistent read/write performance even in metal-dense or compact installations.
Why SICK RFH510-1004301?
Because it delivers reliable identification in tough conditions with smart IO-Link communication and an integrated antenna — all in a compact, industrial-grade housing. The RFH510 transforms standard production lines into intelligent systems that track, record, and respond automatically to every tagged component, boosting both efficiency and precision.
What Problem Does It Solve?
The RFH510-1004301 eliminates manual data entry errors and process blind spots in automated environments. By reading and writing RFID tags instantly at close range, it ensures that every product or tool is recognized correctly, even in metal-rich or space-constrained setups, keeping operations synchronized and traceable from start to finish.
| Feature | Details | Benefit |
|---|---|---|
| Product Type | RFID Read/Write Device with Integrated Antenna | Combines reading and writing functions in a single compact unit for efficient identification. |
| Operating Frequency | 13.56 MHz (HF Band) | Ensures reliable communication with a wide range of industrial RFID tags. |
| RFID Standards | ISO/IEC 15693, ISO/IEC 18000-3 Mode 1 | Guarantees compatibility with global RFID systems. |
| Communication Interface | IO-Link V1.1 | Enables fast integration, real-time diagnostics, and parameterization via PLC or controller. |
| Read Range | Up to 60 mm | Provides accurate tag recognition even in confined or metal-heavy environments. |
| Data Transmission Rate | 26 kbit/s | Maintains quick and stable data transfer between the reader and control system. |
| Optical Indicators | 4 Multi-color LEDs | Offers clear visual feedback for status, power, and data communication during operation. |
| Housing Material | Brass (chromium-plated) with blue PBTP cap | Provides high durability and resistance to oil, vibration, and industrial wear. |
| Protection Rating | IP67 | Ensures reliable operation in harsh environments with dust and moisture exposure. |
| Supply Voltage | 11 V DC to 32 V DC | Supports flexible integration with different industrial power systems. |
| Power Consumption | ≤ 1.8 W | Energy-efficient design reduces system load and heat generation. |
| Connector Type | M12, 4-pin male connector (A-coded) | Simplifies wiring and installation within existing automation setups. |
| Design Form | Cylindrical, M30 x 1.5 thread | Compact form factor ideal for mounting in tight or modular equipment. |
| Operating Temperature | –25 °C to +80 °C | Delivers stable performance across wide environmental conditions. |
| Vibration/Shock Resistance | IEC 60068-2-6 / IEC 60068-2-27 | Withstands demanding motion or mechanical stress in industrial setups. |
| Mean Time To Failure (MTTF) | > 756 years (at 25 °C) | Extremely long service life for continuous operation. |
| Certifications | CE, UKCA, FCC, cULus, China-RoHS | Meets international compliance and quality assurance standards. |
Download SICK RFH510-1004301 (6072841) Datasheet
| Commercial Data | Details |
|---|---|
| Weight | 165 g |
| Country of Origin | Sri Lanka |
In automotive production, tools must be precisely identified and verified at every workstation. The RFH510-1004301 can be mounted near tool racks to automatically detect RFID-tagged equipment. Each tool is confirmed before use, preventing mix-ups and improving workflow accuracy. Its short-range HF design and integrated antenna deliver accurate reads even around metal surfaces, helping technicians maintain full traceability and preventing costly assembly delays caused by missing or incorrect tools.
Electronics manufacturers use numerous process steps that demand continuous tracking. The RFH510-1004301 enables every circuit board or component carrier to be identified automatically as it moves between soldering, testing, and packaging. The IO-Link interface ensures real-time data flow into the factory system, while the precise short-range read zone prevents false triggers from adjacent lines. This provides complete visibility into production progress and enables faster quality analysis and error correction.
In hospitals and medical device factories, it’s critical to verify each instrument after cleaning or sterilization. The RFH510-1004301, with its IP67-sealed housing, can be embedded near sterilization units or storage areas. Tagged medical tools are scanned to record their cleaning cycle and readiness status. This automated tracking reduces manual entry errors, ensures compliance with hygiene standards, and allows accurate usage monitoring throughout the instrument’s life cycle.
Modern data centers require precise control over equipment access and movement. The RFH510-1004301 can be installed in server racks or access gates to identify tagged devices such as blades, storage drives, or modules. Its short-range field ensures only nearby assets are read, improving accuracy in confined rack spaces. Integration with the control system allows secure, traceable access logging—helping prevent unauthorized removal, streamline audits, and enhance overall security management.
| Category | Model / Accessory Name | Part Number | Description & Benefits |
|---|---|---|---|
| RFID Transponder | HF Transponder, On-Metal | 6039051 | Compact rectangular RFID tag with 896-bit user memory (28 × 4 bytes). Designed for reliable performance on metal surfaces—ideal for identifying parts or tools in metal-heavy production areas. |
| Mounting System | BEF-WN-M30 Mounting Bracket | 5308445 | Durable steel bracket for M30-size sensors. Zinc-coated finish prevents corrosion and allows stable, quick installation of the RFH510 reader in industrial setups. |
| Network Device | SIG200-0A0412200 IO-Link Gateway | 1089794 | Industrial IO-Link sensor hub for integrating multiple RFID or sensor devices into PLC networks. Supports data monitoring and centralized system management. |
| Interface Module | IOLA2US-01101 (SiLink2 Master) | 1061790 | IO-Link master module that enables communication, configuration, and diagnostics between RFID readers and automation controllers. Simplifies commissioning and maintenance. |
| Connection Cable | YF2A14-C60UB3M2A14 Sensor Cable | 2095999 | 4-pin M12 straight connector cable (0.6 m, PUR jacket). Resistant to oils, flexing, and mechanical stress—ideal for robotic or dynamic motion applications. |
