$ 65.55
SICK MQ10-60ANSKT0 magnetic sensor with up to 60 mm sensing range. Compact IP67 design for reliable, non-contact position detection in automation.
The SICK MQ10-60ANSKT0 magnetic sensor is a compact solution for long-distance, non-contact position sensing in industrial automation systems. With a detection capability reaching up to 60 mm, it addresses applications where traditional sensors struggle due to contamination, vibration, or mechanical tolerance issues. Its slim rectangular housing supports installation in confined spaces, while the NPN normally open output allows straightforward integration with standard control systems. Designed for demanding environments, the robust IP67 enclosure ensures dependable operation even where moisture, dust, or mechanical stress are present.
Designed for precise magnetic field detection, the MQ10-60ANSKT0 provides consistent switching behavior and high repeatability, supporting reliable end-position and motion monitoring. The fast response capability suits high-speed automation processes, while integrated electrical protections help safeguard connected equipment. Its ability to operate across a wide temperature range makes it suitable for diverse industrial settings. By enabling contactless sensing, the sensor minimizes mechanical wear, lowers maintenance effort, and contributes to longer machine service life and improved overall equipment efficiency.
Why SICK MQ10-60ANSKT0?
The SICK MQ10-60ANSKT0 is engineered for engineers who need dependable position detection without mechanical contact or optical alignment issues. Its extended sensing distance, compact form factor, and stable magnetic response make it ideal for modern machines with tight layouts and fast cycles. Built to endure harsh industrial conditions, it delivers consistent performance while reducing maintenance effort and unplanned downtime, making it a smart long-term choice for reliable automation design.
What problem does it solve?
This sensor solves the challenge of detecting movement or position in environments where dirt, vibration, moisture, or misalignment cause conventional sensors to fail. By using magnetic fields instead of physical contact or light, it ensures accurate switching even when components are hidden, moving rapidly, or exposed to contaminants. The result is more stable machine operation, fewer false signals, and improved process reliability.
| Feature | Details | Benefit |
|---|---|---|
| Sensing Range | 0 … 60 mm | Allows flexible installation with larger mechanical tolerances |
| Safe Sensing Distance | Up to 48.6 mm | Ensures stable detection with high functional safety margin |
| Magnetic Sensitivity | 1 mT | Delivers accurate switching even with compact magnets |
| Switching Output | NPN, Normally Open (NO) | Easy integration with standard PLC and control systems |
| Switching Frequency | Up to 1,000 Hz | Supports fast-moving machinery and high-cycle applications |
| Housing Design | Compact rectangular housing | Ideal for confined installation spaces |
| Dimensions (W × H × D) | 10 × 28 × 16 mm | Simplifies mounting in space-constrained equipment |
| Connection Type | M8 connector, 3-pin | Enables quick, secure, and standardized wiring |
| Electrical Wiring | DC 3-wire | Reduces wiring complexity during system integration |
| Supply Voltage | 10 … 30 V DC | Compatible with common industrial power supplies |
| Current Consumption | Approx. 5 mA (no load) | Improves energy efficiency in continuous operation |
| Response Time | ≤ 26 ms | Ensures timely and precise signal availability |
| Hysteresis | 1 % … 10 % | Prevents signal chatter in vibration-prone environments |
| Protection Functions | Reverse polarity, short-circuit, power-up protection | Increases system reliability and protects connected devices |
| Enclosure Rating | IP67 | Reliable operation in dusty, wet, or washdown environments |
| Housing Material | Plastic (VISTAL®) | Offers durability with chemical and mechanical resistance |
| Operating Temperature | –25 °C … +75 °C | Suitable for a wide range of industrial conditions |
| Shock & Vibration Resistance | Up to 30 g / industrial vibration levels | Maintains performance under mechanical stress |
| Service Life (MTTFd) | Approx. 1,924 years | Supports long-term, maintenance-free operation |
Download SICK MQ10-60ANSKT0 (1078009) Datasheet
| Commercial Data | Details |
|---|---|
| EAN Number | 4047084433641 |
| Weight | 11 g |
| Country of Origin | Malaysia |
In automated machinery, pneumatic cylinders must deliver repeatable motion while operating in environments filled with dust, oil mist, or vibration. The MQ10-60ANSKT0 is mounted externally along the cylinder body to sense the magnetic field of the piston without physical contact. Its extended sensing distance allows reliable detection even through thick cylinder walls or protective covers. High switching speed supports fast stroke movements, while magnetic detection avoids wear-related failures. This approach improves position accuracy, reduces mechanical maintenance, and keeps production lines running consistently over long operating cycles.
Conveyor systems depend on precise position feedback to control stops, transfers, and diverters. The MQ10-60ANSKT0 can be installed along the conveyor structure to detect magnets attached to moving carriers or stoppers. Because magnetic sensing is immune to dirt and vibration, the sensor maintains stable signals in busy material handling environments. Its compact housing fits into narrow frames, and the sealed enclosure tolerates moisture and dust. These characteristics help prevent misalignment errors, support higher throughput, and ensure smooth, repeatable conveyor operation.
Packaging machinery involves frequent movement of guides, sealing jaws, and sliding components, often in dusty conditions. By using the MQ10-60ANSKT0 to detect magnetic targets on moving parts, machines gain non-contact position feedback that remains accurate despite debris or minor misalignment. The sensor’s consistent magnetic sensitivity delivers clean switching signals, reducing false triggers during high-speed cycles. This results in more stable machine timing, fewer interruptions, and improved packaging quality, especially in high-volume production environments.
Adjustable fixtures, lifting mechanisms, and mobile machine components require dependable end-position confirmation under vibration and load changes. The MQ10-60ANSKT0 detects magnet-equipped components without physical contact, maintaining accuracy even when structures flex during motion. Its resistance to shock and wide temperature tolerance support operation across varied industrial settings. The generous sensing distance simplifies mechanical design by allowing looser tolerances, improving safety, reliability, and long-term performance where conventional switches would degrade quickly.
| Category | Model Name | Part Number | Benefits |
|---|---|---|---|
| Sensor Cable | YF8U13-020VA1XLEAX | 2095860 | Straight M8 connector, PVC cable for general industrial wiring |
| YF8U13-050VA1XLEAX | 2095884 | Straight M8 connector with extended cable length | |
| YG8U13-020VA1XLEAX | 2096165 | Angled M8 connector for tight installation spaces | |
| YG8U13-050VA1XLEAX | 2096166 | Angled connector with longer reach | |
| YF8U13-020UA1XLEAX | 2094782 | PUR cable for oil, lubricant, and drag-chain environments | |
| YF8U13-050UA1XLEAX | 2094788 | PUR cable with extended length for dynamic motion | |
| YG8U13-020UA1XLEAX | 2094794 | Angled PUR cable optimized for robotic applications | |
| YG8U13-050UA1XLEAX | 2095586 | Long angled PUR cable for demanding routing paths | |
| YG8U13-C60UA1XLEAX | 2145889 | Compact PUR cable for confined routing | |
| YG8U13-030UA1XLEAX | 2145891 | Mid-length PUR cable balancing flexibility and coverage |
