Name: SICK IQ40-40NNSKC0K Inductive Proximity Sensor - INOSAKI
SKU: SICK-1071854
Price: 51.74 USD
Availability: InStock

Technical Overview

Rectangular inductive proximity sensor featuring a 40mm non-flush sensing range, NPN normally open output, M12 4-pin connection, and rugged IP69K housing.

Key Features

Extended 40 mm non-flush sensing range for reliable long-distance metallic detection
Compact short-body rectangular design measuring 40 mm x 40 mm x 66 mm
NPN Normally Open (NO) switching output configured for DC 3-wire electrical setups
Industry-standard M12, 4-pin male connector for fast, secure integration
IP67, IP68, and IP69K enclosure ratings for maximum resistance to moisture and high-pressure washdowns
Wide 10 V DC to 30 V DC operating voltage range with integrated short-circuit and reverse polarity protection
Durable PA 66 plastic housing and sensing face rated for temperatures from -25 °C to +85 °C

Technical Specification Matrix

Parameter	Value
Housing Type	Rectangular (Short-body)
Dimensions (W x H x D)	40 mm x 40 mm x 66 mm
Sensing Range (Sn)	40 mm
Assured Sensing Range (Sa)	32.4 mm
Installation Type	Non-flush
Switching Frequency	100 Hz
Connection Type	Male connector M12, 4-pin
Switching Output	NPN
Output Function	NO (Normally Open)
Electrical Wiring	DC 3-wire
Enclosure Rating	IP67, IP68, IP69K
Supply Voltage	10 V DC to 30 V DC
Voltage Drop	≤ 2 V
Continuous Current (Ia)	≤ 200 mA
No-Load Current	12.5 mA
Housing Material	Plastic, PA 66
Sensing Face Material	Plastic, PA 66
Ambient Operating Temperature	-25 °C to +85 °C
Physical Weight (kg)	0.15
Dimensions L x W x H (cm)	6.6 x 4 x 4

Industrial Applications

1. Heavy-Duty Conveyor Jam Detection

Deploys alongside industrial conveyor systems to continuously monitor the movement of metallic pallets and components. The extended sensing distance ensures the sensor remains safely out of the direct path of moving objects.

Problem Solved

Prevents mechanical damage and system downtime by detecting metal objects from a safe 40mm standoff distance, avoiding accidental physical collisions while maintaining high detection reliability.

40 mm Sensing RangeNon-flush InstallationNPN Output100 Hz Switching Frequency

2. Automated Washdown Facility Position Sensing

Monitors the state and position of automated heavy gates and large valves within food processing or heavy equipment washdown stations where high-pressure hot water cleaning is routine.

Problem Solved

Eliminates premature sensor failure caused by aggressive water ingress, ensuring reliable target tracking without the need for constant maintenance or protective housings.

IP69K EnclosureIP68 RatingPA 66 Plastic Housing10 to 30 VDC

3. Agricultural Machinery Component Verification

Integrates into mobile and outdoor agricultural equipment to verify the proper deployment and positioning of stabilizing outriggers and mechanical booms in completely exposed environments.

Problem Solved

Provides consistent, non-contact structural metal detection despite severe temperature variations, shock, vibrations, and constant exposure to rain, mud, and dust.

-25 °C to +85 °C Temperature RangeM12 4-Pin ConnectorDC 3-wireNO (Normally Open)
