EZ-BEAM S18 Series: Polarized Retro
Range: 2 m; Input: 10-30 V dc
Output: Complementary PNP
2 m (6.5 ft) Cable
$ 164.22
Banner Sensors
| Sensing Beam | Visible Red LED |
| Cable Length (m) | 2 |
| Power | DC |
| Sensing Mode (General) | Retroreflective |
| Sensing Mode (Detailed) | Polarized |
| Housing Style | Barrel |
| Primary Housing Material | Thermoplastic |
| Input Output | Discrete |
| Max Sensing Distance (mm) | 2000 |
| Outputs | PNP |
| Power Supply/Supply Voltage | 10-30 V dc |
| Connection | Cable |
| Min Op. Temp. (°C) | -40 |
| Operation | Light/Dark Operate |
| Max Op. Temp. (°C) | 70 |
| Output response time (ms) | 3 |
| Special Feature: Intrinsically Safe | No |
| Special Feature: Remote Teach | No |
| Special Feature: Water Detection | No |
| Delay at Power-up (ms) | 100 |
| Repeatability (µs) | 750 |
| Number of Pins | 4 |
| IP Rating | IP67, IP69K |
| NEMA Rating | NEMA 6P |
| Max Op. Relative Humidity [%] | 90% @ 50°C |
| Lens Material | Acrylic |
| Adjustments | N/A |
| Barrel Diameter (mm) | 18 |
| Indicator | LEDs |
| Feature: Washdown Rated | Yes |
| Feature: Timing (Hold/Delay) | No |
| Feature: Ecolab Certified | Yes |
| Feature: Encapsulated | Yes |
| Feature: Audible | No |
| Feature: Quick Disconnect | No |
| Feature: Health/ Marginal Signal Output | Yes |
