$ 196.46
Banner produce industrial sensors range such as laser distance measurement sensors, photoelectric sensors, fiber optic sensors, fiber optic sensors amplifiers sensors, temperature & vibration sensors, slot, label and arrays, registration mark, color and luminescence sensors, pick-to-light sensors.
WORLD-BEAM Q12 Series: Fixed-Field
Range: 15 mm; Input 10-30V dc
Output: LO (Light Operate) Bipolar: 1 NPN; 1 PNP
Euro (M12) 150 mm (6 in) Pigtail QD
| Article Number | 74141 |
| Cable Length (m) | 0.15 |
| Sensing Beam | Visible Red LED |
| Power | DC |
| Sensing Mode ( General ) | Proximity |
| Sensing Mode ( Detailed ) | Background Suppression (Fixed) |
| Housing Style | Rectangular |
| Primary Housing Material | Thermoplastic |
| Small Visible Spot | LED |
| Input / Output | Discrete |
| Max Sensing Distance (mm) | 15 |
| Outputs | Bipolar (NPN & PNP) |
| Power Supply / Supply Voltage | 10-30V dc |
| Connection | Pigtail QD |
| Quick Disconnect Type | M12 (Euro) |
| Min Op. Temp. (°C) | -20 |
| Operation | Light Operate |
| Max Op. Temp. (°C) | 55 |
| Output response time (ms) | 0.85 ON/OFF |
| Special Feature : Intrinsically Safe | No |
| Special Feature : Remote Tech | No |
| Special Feature : Water Detection | No |
| Sensing Beam Wavelength | 640 |
| Delay at Power-up (ms) | 120 |
| Repeatability (µs) | 175 |
| Number of Pins | 4 |
| IP Rating | IP67 |
| Max Op. Relative Humidity [%] | 95% @ 50°C |
| Lens Material | Polycarbonate |
| Adjustments | N/A |
| Barrel Diameter (mm) | N/A |
| Indicator | LEDs |
| Feature : Timing (Hold / Delay) | No |
| Feature : Encapsulated | No |
| Feature : Hazardous Area | No |
| Feature : Audible | No |
| Feature : Chemical Resistant | No |
| Feature : Quick Disconnect | Yes |
| DeviceNet | No |
| IO Link | No |
