Name: Phoenix Contact STTB 2,5_2P Double-Level Terminal Block - INOSAKI
SKU: Phoenix-3040054
Price: 7.71 USD
Availability: InStock

Technical Overview

Double-level terminal block for spring-cage/plug-in connections, 500V, 22A. Supports 0.08-4mm² conductors, DIN rail mountable. Tested for railway applications.

Key Features

Spring-cage/plug-in connection for simple conductor installation.
Double-level design allows the connection of more than one conductor.
Compact design for maximum space savings.
Tested for railway applications (e.g., DIN EN 50155).
Mounts onto NS 35/7.5 and NS 35/15 DIN rails.
Insulating material: Polyamide (PA), gray color.

Technical Specification Matrix

Parameter	Value
Number of Levels	2
Connection Method	Spring-cage/plug-in connection
Nominal Voltage	500 V
Nominal Current	22 A (with 2.5mm² conductor)
Rated Cross Section	2.5 mm²
Conductor Cross Section Rigid Min	0.08 mm²
Conductor Cross Section Rigid Max	4 mm²
Conductor Cross Section Flexible Min	0.08 mm²
Conductor Cross Section Flexible Max	2.5 mm²
Conductor Cross Section AWG Min	28
Conductor Cross Section AWG Max	12
Stripping Length	8 mm ... 10 mm
Rated Surge Voltage	6 kV
Degree of Pollution	3
Insulating Material	PA (Polyamide)
Flammability Rating (UL 94)	V0
Color	Gray
Mounting Type	DIN rail NS 35/15, NS 35/7,5
Static Insulating Material Application in Cold	-60 °C
Physical Weight (kg)	0.01
Dimensions L x W x H (cm)	7.15 x 0.52 x 4.75
