1. High-Speed Parts Counting on Conveyors
In automated manufacturing, the sensor is used to count small metal components like screws or gears as they move rapidly on a conveyor belt. The sensor is mounted just above or beside the belt to detect each passing part.
Problem SolvedIts high 1.5kHz response frequency ensures that no part is missed, even at maximum conveyor speed, providing an accurate count for inventory and packaging processes. The shielded M8 body allows for flush mounting in metal guides without interference.
High-Speed CountingConveyor AutomationSmall Part DetectionAssembly LinePNP Output
2. Tool Position Verification in CNC Machining Centers
The sensor is installed within the tool changing mechanism of a CNC machine to confirm that a metal tool holder is correctly seated in the spindle or that the tool turret has indexed to the correct position.
Problem SolvedThe sensor's precise 0 to 1.6mm stable sensing range provides reliable go/no-go position confirmation. Its IP67 stainless steel construction ensures it withstands harsh environments with coolants, lubricants, and metal chips, preventing machine damage and scrap parts.
CNC Tool DetectionHome Position SensingTurret IndexingMachine Tool AutomationStainless Steel Body
3. Actuator End-of-Stroke Detection in Pneumatics
In automated assembly or robotics, the sensor is mounted to a pneumatic cylinder to detect when the piston has reached its fully extended or retracted position, confirming the completion of a clamping or pushing action.
Problem SolvedThe compact M8 size allows for easy integration into tight machine spaces. Its reliable detection of the metal piston provides a critical feedback signal to the PLC, ensuring process steps occur in the correct sequence and preventing system errors or collisions.
Cylinder Position SensingEnd-of-Stroke DetectionPneumatic ActuatorRoboticsPLC Feedback
