OV-24DC/ 60DC/4 – 2982647 – Phoenix Contact Semi-Conductor Relay
$ 22.66
SKU: Phoenix Contact 2982647
Input Data
| Nominal input voltage UN | 24 V DC |
| Input voltage range | 4.25 V DC … 32 V DC |
| Switching threshold “0” signal, voltage | < 1 V DC |
| Switching threshold “1” signal voltage | > 3.3 V DC |
| Typical input current at UN | 15 mA |
| Typical response time | < 100 µs |
| Typical turn-off time | < 250 µs |
| Transmission frequency | 100 Hz |
Output Data
| Design of digital output | electronic |
| Output voltage range | 1 V DC … 60 V DC |
| Limiting continuous current | 4 A (see derating curve) |
| Min. load current | 1 mA |
| Leakage current | 100 µA |
| Surge current | 25 A (tp = 1 s) |
| Voltage drop at max. limiting continuous current | 0.5 V |
| Output circuit | 2-conductor |
| Protective circuit | Reverse polarity protection; Polarity protection diode |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 80 °C |
| Ambient temperature (storage/transport) | -20 °C … 80 °C |
Standards and Regulations
| Standards/regulations | EN 61000-4-2 |
| EN 61000-4-3 | |
| EN 61000-4-4 | |
| EN 55011 |
Commercial Data
| Item number | 2982647 |
| Packing unit | 10 pc |
| Minimum order quantity | 1 pc |
| Product Key | CK7121 |
| Catalog Page | Page 559 (C-7-2013) |
| GTIN | 4046356131971 |
| Weight per Piece (including packing) | 25.6 g |
| Weight per Piece (excluding packing) | 24 g |
| Customs tariff number | 85362010 |
| Country of origin | CN |
Dimensions
| Dimensional drawing |  |
| Width | 10.5 mm |
| Height | 43 mm |
| Depth | 25.4 mm |
| Weight | 0.024 kg |
|---|---|
| Dimensions | 2.54 × 1.05 × 4.3 cm |
