Omron TL-N20ME1 2M is an unshielded 20 mm NPN proximity sensor with a 2 m cable, IP67 rating and oil-resistant construction.
The Omron TL-N20ME1 2M is an unshielded rectangular inductive proximity sensor with a 20 mm nominal sensing distance, DC three-wire NPN output and 2 m pre-wired cable. Its normal-open output is rated for up to 200 mA at 24 VDC, and the sensor operates from 10 to 30 VDC. The sensor head measures 25 × 25.5 × 38.20 mm; the enclosure is rated IP67 and meets Omron's oil-proof internal standard. Omron listed this exact model as selling and standard-stock in its 2026-09-11 status record.
A 20 mm unshielded NPN inductive sensor for non-contact detection of ferrous targets.
| Parameter | Value |
|---|---|
| Product type | Rectangular unshielded inductive proximity sensor |
| Sensing distance | 20 mm ±10% |
| Setting distance | 0 to 16 mm |
| Differential distance | 15% max. of sensing distance |
| Standard sensing object | Iron, 50 × 50 × 1 mm |
| Sensing target material | Ferrous metal; sensing distance decreases with non-ferrous metals |
| Response frequency | 40 Hz average |
| Power supply voltage | 12 to 24 VDC, ripple 10% p-p max. |
| Operating voltage range | 10 to 30 VDC |
| Current consumption | 8 mA max. at 12 VDC; 15 mA max. at 24 VDC |
| Control output | NPN, DC 3-wire, normally open; 100 mA max. at 12 VDC and 200 mA max. at 24 VDC |
| Residual voltage | 1 V max. at 200 mA load current |
| Protection rating | IEC 60529 IP67; Omron internal oil-proof standard |
| Connection | Pre-wired, 2 m cable |
| Sensing head dimensions | 25 × 25.5 × 38.20 mm |
| Housing material | Heat-resistant ABS resin |
| Accessories | Instruction manual, mounting bracket and Phillips mounting screw |
| Physical Weight (kg) | 0.340 (approx., packaged). |
| Dimensions L x W x H (cm) | See the Omron drawing; the manufacturer lists the sensing head size as 40 × 41 × 53 mm (cable excluded). |
| Supply status | Active; Omron listed TL-N20ME1 2M as selling and standard-stock on 2026-09-11; stock indicator 〇. |
Engineering suggestions require suitability checks for your installation.
The sensor is rated for non-contact detection of ferrous metal at a nominal 20 mm distance.
Position a ferrous target within the 0 to 16 mm setting distance and verify the response with the actual target size and orientation.
An NPN normally-open output can signal when a ferrous machine part enters the sensing zone.
Connect the sensor to a compatible 10 to 30 VDC input and maintain the specified clearance from nearby metal and adjacent sensors.
