Name: Omron R87F-A4A85HP AC Axial Fan - INOSAKI
SKU: Omron-R87F-A4A85HP
Price: 52.22 USD
Availability: InStock

Technical Overview

The Omron R87F-A4A85HP is a highly reliable industrial-grade AC axial fan engineered for efficient heat dissipation in electronic enclosures and machinery. Measuring 80 x 80 x 38 mm, it features a rugged aluminum die-cast frame paired with durable glass polycarbonate blades for enhanced environmental resistance. Operating at 200 VAC, it utilizes a single-phase shading coil induction motor equipped with precision ball bearings to ensure an extended service life and low acoustic noise. Designed for high-speed performance, the fan delivers a maximum volumetric airflow of up to 0.9 m³/min, effectively minimizing thermal stress in enclosed control panels and power systems. Built-in impedance protection reliably prevents motor burnout during locked-rotor conditions, increasing overall operational safety.

Key Features

High-speedACaxialfanoperatingat2, 700/3, 200RPM(50/60Hz)forrobustcoolingperformance[1.1].
Compact 80x80x38 mm form factor featuring an aluminum die-cast housing and glass polycarbonate blades.
Equipped with precision ball bearings for minimized mechanical noise and a prolonged service life.
Features convenient terminal-type connections for simplified panel wiring and quick installation.
Integrates motor impedance protection to prevent overheating during obstructed or locked-rotor scenarios.
Supports a broad operating temperature range of -30°C to 70°C without icing.

Technical Specification Matrix

Parameter	Value
Dimensions	80 x 80 x 38 mm
Rated Voltage	200 VAC
Frequency	50/60 Hz
Rated Current	0.080 A (50 Hz) / 0.060 A (60 Hz)
Power Consumption	10 W (50 Hz) / 9 W (60 Hz)
Rotational Speed	2,700 RPM (50 Hz) / 3,200 RPM (60 Hz)
Maximum Airflow	0.8 m³/min (50 Hz) / 0.9 m³/min (60 Hz)
Maximum Static Pressure	42.1 Pa (50 Hz) / 58.8 Pa (60 Hz)
Acoustic Noise	32 dB (50 Hz) / 36 dB (60 Hz)
Motor Protection	Impedance Protection
Operating Temperature	-30°C to 70°C (no icing)
Connection Type	Terminals
Weight	Approx. 280 g

Industrial Applications

1. Control Panel Thermal Management

Programmable logic controllers (PLCs), drives, and relay arrays housed inside factory automation control cabinets generate heat that can precipitate component failure or thermal throttling.

Problem Solved

By mounting the Omron R87F-A4A85HP, panel builders secure active heat extraction, driving up to 0.9 m³/min of airflow to continuously regulate internal enclosure temperatures up to 70°C.

200 VAC0.9 m³/min Airflow58.8 Pa Static PressureControl Cabinet Ventilation

2. Industrial Power Supply Cooling

High-power industrial transformers and power supply units experience immense thermal stress under peak loading, necessitating mechanical cooling to prevent dangerous overheating and voltage drops.

Problem Solved

The fan’s aluminum die-cast frame and resilient ball-bearing operation ensure steady, high-speed heat dissipation directly over vital heat sinks and transformer coils, protecting sensitive power components.

Aluminum Die-Cast FrameImpedance ProtectionHigh-Speed Operation3,200 RPM

3. Server and Telecommunications Equipment Rack Ventilation

Densely packed server chassis and network equipment installations frequently develop localized thermal hotspots, challenging hardware stability and operational efficiency.

Problem Solved

Its compact 80x80x38 mm dimensions allow seamless rack integration, while its precision engineering provides effective airflow against system impedance, all while maintaining low acoustic noise profiles around 32-36 dB.

Ball Bearings80x80x38 mmLow Acoustic NoiseRack Ventilation
