1. Small-Scale Bottling Line Control
Utilized as the primary operator interface on a compact bottling line for controlling conveyor speed, fill levels, and capping mechanisms. The operator can easily monitor production counts, view alarm statuses, and select different product recipes.
Problem SolvedProvides a centralized, intuitive control and monitoring point for a multi-stage process, replacing numerous physical buttons and indicators. The IP65 front panel ensures reliability in an environment with potential for liquid splashes.
HMIRecipe ManagementIP65PLC IntegrationMachine Control
2. HVAC System Monitoring for a Commercial Building
Deployed as a central monitoring panel for a building's HVAC system. Maintenance personnel can view real-time temperature data from multiple zones, monitor fan and pump status, and adjust setpoints.
Problem SolvedThe Ethernet connectivity allows the HMI to communicate with multiple networked temperature controllers and PLCs. The 7-inch color screen provides a clear and comprehensive graphical overview of the entire system, simplifying diagnostics and operation.
Data VisualizationEthernet TCP/IPHVAC ControlBuilding AutomationRemote Monitoring
3. Operator Interface for a Plastic Injection Molding Machine
Serves as the operator's main interface for setting up and running a plastic injection molding machine. The HMI is used to input process parameters like temperature, pressure, and injection times, and to display cycle progress and production data.
Problem SolvedThe unit's 24V DC power supply is standard for industrial control panels. The clear, responsive touchscreen and data logging capabilities allow for precise process control and quality monitoring, while the USB port facilitates easy data extraction for analysis.
Process ControlData Logging24V DCIndustrial AutomationInjection Molding
