Omron E3Z-LT61 2M: laser through-beam (emitter and receiver set), 60 m, NPN output, 12–24 V DC and IP67.
The Omron E3Z-LT61 2M is a compact laser photoelectric sensor using laser through-beam (emitter and receiver set). Its manufacturer-rated sensing performance is 60 m; this exact variant has NPN open collector and a 2 m pre-wired cable. It uses a 655 nm Class 1 red laser, operates from 12–24 V DC ±10%, and is rated IP67 for industrial installations. Supply status is recorded as Unknown because current supply was not established.
Laser through-beam (emitter and receiver set); 60 m; NPN output, 2 m pre-wired cable, 12–24 V DC, IP67.
| Parameter | Value |
|---|---|
| Product type | Laser through-beam (emitter and receiver set) |
| Sensing method | Laser through-beam (emitter and receiver set) |
| Sensing distance | 60 m |
| Light source | Red laser diode, 655 nm, Class 1; 5 mm spot at 3 m |
| Laser safety class | Class 1 (JIS, IEC/EN, FDA, GB/T) |
| Output | NPN open collector; open collector; 100 mA max.; 26.4 V DC max. load supply |
| Response time | 1 ms max. |
| Operation mode | Selectable Light-ON / Dark-ON |
| Power supply | 12–24 V DC ±10%; 10% max. peak-to-peak ripple |
| Current consumption | 35 mA total (emitter 15 mA, receiver 20 mA) |
| Connection | 2 m pre-wired cable |
| Operating temperature | −10 to 55 °C (no icing or condensation) |
| Storage temperature | −25 to 70 °C (no icing or condensation) |
| Relative humidity | Operating 35–85%; storage 35–95% (no condensation) |
| IP rating | IP67 (IEC 60529) |
| Housing material | PBT case; lens material varies by sensing family |
| Physical Weight (kg) | 0.120 kg (approx., packed state) |
| Dimensions L x W x H (cm) | Approx. 3.1 × 1.27 × 2.54 cm; see manufacturer drawing for orientation |
Engineering suggestions require suitability checks for your installation.
Detect and count passing items using laser through-beam (emitter and receiver set) in a machine or conveyor station.
The 60 m rating provides a basis for layout; validate alignment, target properties, sensing margin and reflector requirements at the installation.
Monitor part presence or passage at a guarded packaging or assembly station.
Use the selectable Light-ON / Dark-ON output and 2 m pre-wired cable; confirm wiring, target geometry and environmental suitability during commissioning.
