Omron E3X-ZV41 2M smart fiber amplifier with PNP open collector, 2 m prewired cable and 12 to 24 VDC supply.
The E3X-ZV41 2M is a one-channel standard fiber amplifier in Omron's E3X-ZV family. It has a PNP open collector output and a 2 m prewired cable. The red 625 nm LED amplifier supports smart tuning for setting light intensity and threshold using a compatible Omron fiber unit. Select the fiber head for the application and configure response mode to suit the machine cycle.
One-channel smart fiber amplifier with PNP open collector output and 2 m prewired cable.
| Parameter | Value |
|---|---|
| Manufacturer | Omron |
| Series | E3X-ZV |
| Product type | One-channel smart fiber amplifier |
| Output | PNP open collector |
| Inputs/outputs | 1 output |
| Connection | Prewired cable, 2 m |
| Rated supply voltage | 12 to 24 VDC ±10% |
| Light source | Red 4-element LED, 625 nm |
| Response time | 50 μs SHS; 250 μs HS; 1 ms standard; 16 ms GIGA |
| Degree of protection | IP50 with protective cover |
| Supply status | Unknown; current manufacturer supply status was not established. |
| Physical Weight (kg) | Not stated in the checked manufacturer product data. |
| Dimensions L x W x H (cm) | See manufacturer dimensional data; no complete overall L × W × H value stated. |
Engineering suggestions require suitability checks for your installation.
Use a compatible fiber unit to detect small parts or targets in constrained machine layouts.
Choose the fiber head based on target size, sensing direction and required working distance.
Provide a discrete output from an optical fiber detection point to machine control.
Connect the PNP open collector to a compatible PLC input and tune the threshold for the actual target.
