Omron E32-ZT11L 2M is an M4 through-beam fiber head with a 2 m cable, 700 mm catalog sensing distance, 1.4 mm optical axis and R25 bend radius.
The Omron E32-ZT11L 2M is a long-distance through-beam fiber sensor head with an M4 threaded head and a 2 m free-cut fiber cable. Omron's E3X-ZD catalog lists a 700 mm sensing distance with that amplifier family, a 1.4 mm optical axis, a representative 0.01 mm minimum detectable object, and a 25 mm minimum bend radius. It is a passive optical head and requires a compatible Omron fiber amplifier; the checked manufacturer catalog confirms its specifications, while current supply status is unknown.
M4 through-beam fiber head with 2 m cable, 700 mm catalog range and R25 bend radius.
| Parameter | Value |
|---|---|
| Product type | Through-beam fiber optic sensor head |
| Sensing method | Through-beam |
| Head style | M4 threaded, straight head |
| Fiber length | 2 m; free cut |
| Sensing distance | 700 mm with Omron E3X-ZD amplifier (manufacturer catalog value) |
| Optical axis | 1.4 mm |
| Minimum detectable object | 0.01 mm representative value in Omron catalog |
| Minimum bend radius | 25 mm |
| Compatible amplifier | Omron E3X-ZD family; confirm amplifier compatibility and operating mode before installation |
| Physical Weight (kg) | Not stated in the checked manufacturer catalog. |
| Dimensions L x W x H (cm) | Not stated as an overall L × W × H value in the checked manufacturer catalog. |
| Supply status | Unknown; exact manufacturer specifications confirmed, current supply status not established. |
Engineering suggestions require suitability checks for your installation.
A through-beam optical path can detect small opaque parts across a production fixture where an electrical sensor body would be difficult to place.
Mount the M4 head pair across the detection path, connect to a compatible Omron fiber amplifier, and verify range with the actual target and installation geometry.
Remote fiber heads can fit into narrow machine fixtures while the amplifier remains mounted in an accessible control area.
Route the 2 m fiber with at least a 25 mm bend radius and validate detection and environmental suitability for the machine.
