USD 359.88
24 VDC compact PLC CPU with 60 built-in I/O, sourcing transistor outputs, 10K-step memory, and up to 180 total I/O.
Compact CP2E-series PLC CPU for small to medium machines with 60 built-in I/O points, 24 VDC supply, sourcing transistor outputs, and built-in Ethernet-oriented machine communication capability. The unit supports up to 180 total I/O with expansion, 10K-step program capacity, and function blocks for data collection, Modbus communication, and PID control. Manufacturer documentation lists the exact model as a 24 VDC CP2E-N60D type with 36 inputs and 24 outputs in a compact panel-mounted CPU enclosure.
| Parameter | Value |
|---|---|
| Supply voltage | 24 VDC |
| Operating voltage range | 20.4 to 26.4 VDC |
| Built-in I/O points | 60 |
| Input count | 36 |
| Output count | 24 |
| Output type | Transistor (sourcing) |
| Program capacity | 10K steps |
| FB capacity | 10K steps |
| Maximum total I/O points | 180 |
| Expansion I/O / Expansion Units | Up to 3 units |
| Dimensions (H × D × W) | 90 mm × 80 mm × 195 mm |
| Total height with mounting brackets | 110 mm |
| Weight | 780 g max. |
| Ambient operating temperature | -20 to 60 °C |
| Ambient humidity | 10% to 90% |
| Storage temperature | -20 to 75 °C (excluding battery) |
| Pollution degree | 2 or less |
| Overvoltage category | Category II |
| Noise resistance | 2 kV on power supply line |
| Vibration resistance | Conforms to IEC60068-2-6 |
| Shock resistance | 147 m/s², 3 times in X, Y, and Z directions |
| Terminal screw size | M3 |
| Grounding method | Ground to 100 Ω or less |
| Power consumption | 20 W max. (DC power, maximum system configuration) |
| Inrush current | 24 VDC, 30 A for 20 ms max. at cold start |
The 24 VDC supply, 60 built-in I/O points, and 180-point expansion ceiling fit a compact packaging machine with multiple sensors, actuators, and interlocks.
Consolidates machine sequencing and discrete control in a small panel footprint without needing a larger PLC platform.
The CPU’s high-speed counter functions and 10K-step program capacity suit coordinated indexing, counting, and reject logic in discrete material-handling systems.
Provides deterministic pulse counting and machine sequencing for indexed motion and part counting.
Built-in Ethernet-oriented CP2E positioning and function blocks for Modbus/PID make it suitable as a local controller for machine-to-machine data exchange and supervision.
Enables integration of local machine control with upstream data collection, recipe handling, and basic process regulation.
