USD 306.61
Compact 24 VDC PLC CPU with 36 DI, 24 NPN DO, dual Ethernet, 20K steps, and expandable I/O for machine control.
Compact CP2E network-type PLC CPU unit with 36 digital inputs, 24 NPN transistor outputs, 24 VDC supply, built-in Ethernet TCP/IP, and support for expansion I/O and optional analog boards. The platform targets machine control applications requiring a small footprint, fast execution, and flexible communications.
| Parameter | Value |
|---|---|
| Supply voltage type | DC |
| Supply voltage | 24 VDC |
| Digital inputs | 36 |
| Digital outputs | 24 |
| Output type | NPN transistor |
| Built-in I/O | 60 |
| Program capacity | 20 K steps |
| Data memory capacity | 16 K words |
| Logic execution time | 0.23 µs |
| Communication port(s) | Ethernet TCP/IP |
| Number of Ethernet ports | 2 |
| Number of USB ports | 0 |
| Number of RS-232 ports | 0 |
| Number of RS-485 ports | 0 |
| Communication option(s) | Serial RS-232C, Serial RS-422, Serial RS-485 |
| Number of encoder input channels | 6 |
| Max. encoder input frequency | 100 kHz |
| Max. number of PTP axes | 4 |
| Max. pulse output frequency | 100 kHz |
| Battery-free memory backup | True |
| Real-time clock | True |
| Analogue option boards | True |
| Max. number of analogue I/O channels | 32 |
| Max. number of local I/O points | 180 |
| Max. number of expansion units | 3 |
| Built-in auxiliary 24 VDC output | 0 mA |
| Operating temperature range | -20 to 60 °C |
| Product height (unpacked) | 90 mm |
| Product width (unpacked) | 195 mm |
| Product depth (unpacked) | 80 mm |
| Product weight (unpacked) | 745 g |
The 24 VDC supply, 36 inputs, 24 transistor outputs, and fast 0.23 µs execution support deterministic control of sensors, solenoids, and interlocks in compact packaging lines.
Integrates dense machine I/O without requiring a large controller rack.
With up to 4 PTP axes, 100 kHz pulse output, and encoder inputs, the controller can coordinate small motion and indexing stations.
Provides motion-capable control for simple multi-axis positioning tasks.
Dual Ethernet, serial communications options, and up to 180 local I/O points make it suitable for distributed conveyor cells that need expansion and network integration.
Supports scalable I/O and industrial networking in modular lines.
