USD 270.39
24 VDC compact PLC CPU with 24 inputs, 16 relay outputs, Ethernet TCP/IP, 20K steps, and 3 expansion-unit support.
Compact Omron CP2E network-model PLC CPU unit with 24 VDC supply, 24 digital inputs, 16 relay outputs, integrated Ethernet TCP/IP, and 20K-step program capacity. The platform supports up to 3 expansion units, battery-free memory backup, real-time clock, and optional serial communication boards. Manufacturer literature identifies the unit as a 40-point controller with 16K words of data memory and 160 max local I/O points.
| Parameter | Value |
|---|---|
| Supply voltage type | DC |
| Input type | PNP/NPN |
| Number of digital inputs | 24 |
| Output type | Relay |
| Number of digital outputs | 16 |
| Program capacity | 20 K steps |
| Data memory capacity | 16 K words |
| Logic execution time | 0.23 µs |
| Communication port(s) | Ethernet TCP/IP |
| Number of Ethernet ports | 2 |
| Number of USB ports | 0 |
| Number of RS-232 ports | 0 |
| Number of RS-485 ports | 0 |
| Communication option(s) | Serial RS-232C, Serial RS-422, Serial RS-485 |
| Number of encoder input channels | 6 |
| Max. encoder input frequency | 100 kHz |
| Max. number of PTP axes | 0 |
| Max. pulse output frequency | 0 kHz |
| Function Block programming | Supported |
| Battery-free memory backup | Supported |
| Real-time clock | Supported |
| Analogue option boards | Supported |
| Max. number of analogue I/O channels | 32 |
| Max. number of local I/O points | 160 |
| Max. number of expansion units | 3 |
| Built-in auxiliary 24 VDC output | 0 mA |
| Operating temperature range | -20 to 60 °C |
| Product Height (unpacked) | 90 mm |
| Product Width (unpacked) | 150 mm |
| Product Depth (unpacked) | 80 mm |
| Product Weight (unpacked) | 165 g |
A compact machine controller needing 24 VDC field inputs and relay outputs for solenoids, lamps, and contactor coils can use the integrated 24/16 I/O and relay stage directly.
Eliminates separate interposing relays for many low-power loads while keeping wiring simple in a small panel.
A compact OEM system can be networked through the built-in Ethernet TCP/IP port for HMI, SCADA, or remote maintenance without adding a communication module.
Provides native industrial Ethernet connectivity in a small PLC footprint.
A motion-adjacent conveyor or registration process can exploit the 6 encoder input channels and 100 kHz max encoder frequency for pulse-based position feedback.
Handles high-speed pulse counting for registration, counting, and simple synchronization tasks.
