24 VDC compact PLC CPU with 12 DI, 8 sourcing transistor DO, Ethernet TCP/IP, 20 local I/O, 20K steps, 16K words.
Compact Omron CP2E network CPU unit for 24 VDC control panels, with 12 digital inputs, 8 transistor sourcing outputs, Ethernet TCP/IP, and 20 local I/O points. The manufacturer datasheet lists a 20K-step program capacity, 16K-word data memory, 0.23 µs logic execution time, up to 100 kHz pulse output, and support for encoder inputs and optional serial communications. It is a panel-mounted PLC CPU intended for small machine automation and embedded control architectures.
| Parameter | Value |
|---|---|
| Supply voltage | 24 VDC |
| Input type | PNP/NPN |
| Digital inputs | 12 |
| Digital outputs | 8 |
| Output type | Transistor (sourcing) |
| Program capacity | 20 K steps |
| Data memory capacity | 16 K words |
| Logic execution time | 0.23 µs |
| Communication port(s) | Ethernet TCP/IP |
| Number of Ethernet ports | 1 |
| USB ports | 0 |
| RS-232 ports | 0 |
| RS-485 ports | 0 |
| Communication options | Serial RS-232C, Serial RS-422, Serial RS-485 |
| Encoder input channels | 6 |
| Max. encoder input frequency | 100 kHz |
| Max. number of PTP axes | 2 |
| Max. pulse output frequency | 100 kHz |
| Max. local I/O points | 20 |
| Mounting | Panel mounted |
| Bare product dimensions (H × D × W) | 90 mm × 80 mm × 86 mm |
| Bare product weight | 340 g max. |
The 24 VDC CPU with 12 inputs, 8 transistor outputs, and Ethernet is well suited to compact conveyor stations that need fast discrete sequencing and networked supervision.
Controls sensors, actuators, and remote status exchange in a small footprint without a separate larger PLC.
The 0.23 µs logic execution time, 100 kHz pulse output, and 2-axis PTP support make it suitable for compact packaging machines with synchronized motion or indexing.
Provides deterministic control for indexing, labeling, or counting tasks that require fast pulse generation.
A 20 I/O CPU with serial communication options and Ethernet can replace legacy control relays in retrofit projects while preserving space inside an existing enclosure.
Modernizes discrete machine control and communications without increasing panel size significantly.
