USD 114.85
14-point network CPU with 8 DI, 6 transistor sinking DO, 100–240 VAC supply, Ethernet, 10K-step program capacity.
Network-model CP2E CPU unit with 14 total I/O points, 8 digital inputs, 6 transistor sinking outputs, and 100 to 240 VAC supply. The official datasheet lists 10K-step program capacity, 16K words data memory, built-in Ethernet on the N-series, and compact DIN-rail panel mounting for small machine control and communication tasks.
| Parameter | Value |
|---|---|
| Supply voltage | 100 to 240 VAC, 50/60 Hz |
| Operating voltage range | 85 to 264 VAC |
| I/O count | 14 points total |
| Inputs | 8 digital inputs |
| Outputs | 6 outputs |
| Output type | Transistor (sinking) |
| Program capacity | 10K steps (FB capacity: 10K steps) |
| Data memory capacity | 16K words |
| Current consumption at 5 VDC | 0.21 A |
| Current consumption at 24 VDC | 0.02 A |
| Power consumption | 15 VA/100 VAC max; 25 VA/240 VAC max |
| Inrush current | 120 VAC, 20 A for 8 ms max; 240 VAC, 40 A for 8 ms max |
| External power supply | Not provided for CP2E-@14/20D@-A |
| Mounting type | DIN rail |
| Termination style | Screw terminal |
| Operating temperature | -20°C to 60°C |
| Ethernet | 100BASE-TX and 10BASE-T Auto-MDIX on N-series; 1 port for 14/20-point CPU units |
| Enclosure mounted | Mounted in a panel |
| Dimensions (H × D × W) | 90 mm × 80 mm × 86 mm |
| Weight | 335 g max. |
The 14-point I/O set and built-in Ethernet suit compact packaging machines that need a small PLC with network connectivity and limited discrete field devices.
Replaces oversized controllers in space-constrained packaging panels while keeping Ethernet connectivity for HMI or upstream coordination.
Eight inputs and six transistor sinking outputs are well matched to sensors, relays, and actuator commands in small conveyor or transfer lines.
Provides simple deterministic control for indexing, photoeye logic, and reject actuation without unnecessary controller overhead.
The AC-powered CPU with compact enclosure dimensions and panel mounting supports small skids that need local logic, alarms, and Ethernet diagnostics.
Delivers local control and remote communications in a minimal panel footprint with reduced wiring complexity.
