14-point 24 VDC PLC CPU with relay outputs, 10K-step program memory, 16K-word data memory, and compact panel-mount form factor.
Network-model CP2E CPU unit with 14 I/O points, 24 VDC supply, and relay outputs. The manufacturer datasheet lists 8 inputs and 6 outputs, 10K-step program capacity, 16K-word data memory, and compact panel-mounted construction for small machine control and I/O expansion applications.
| Parameter | Value |
|---|---|
| Power supply | 24 VDC |
| Operating voltage range | 20.4 to 26.4 VDC |
| I/O points | 14 total |
| Inputs | 8 |
| Outputs | 6 |
| Output type | Relay |
| Program capacity | 10K steps (FB capacity: 10K steps) |
| Data memory capacity | 16K words |
| Current consumption at 5 VDC | 0.15 A |
| Current consumption at 24 VDC | 0.05 A |
| Enclosure | Mounted in a panel |
| Dimensions (H × D × W) | 90 mm × 80 mm × 86 mm |
| Weight | 335 g max. |
Best suited for compact OEM machinery that needs 8 digital inputs and 6 relay outputs with 24 VDC control power and a small panel footprint.
Provides basic machine logic, interlocks, and actuator switching in a minimal space envelope.
Appropriate for short conveyor cells, transfer tables, and standalone stations where low I/O count and relay outputs simplify motor starter or contactor interfacing.
Eliminates the need for a larger controller when the machine only requires modest discrete I/O and straightforward wiring.
Useful in retrofit projects where an existing 24 VDC panel needs a modern compact CPU with relay outputs and a small mounting envelope.
Fits constrained control cabinets while preserving easy integration with field devices and hardwired loads.
