32-point PNP transistor output expansion module for Omron CP1 PLCs. 24 VDC sourcing outputs with 0.3 A capacity per point, ideal for high-density control of conveyor sorting and factory annunciator systems.
The Omron CP1W-32ET1 is a high-density industrial digital I/O expansion module engineered for the SYSMAC CP1E, CP1H, and CP1L series of Programmable Logic Controllers (PLCs). This robust unit adds 32 channels of PNP (sourcing) transistor outputs to the automated system, allowing precise control over a vast array of field devices such as relays, contactors, indicator lights, and pneumatic solenoids. Designed for rapid-response applications, it features an ultra-fast 0.1 to 1 ms OFF/ON delay time. Operating with a versatile 4.5 to 30 VDC permitted output voltage range and delivering 0.3 A of output current per point, the module optimizes control cabinet space via its standard DIN-rail mounting form factor and IP20-rated protection.
| Parameter | Value |
|---|---|
| Module Type | Digital Output Expansion Unit |
| Number of Digital Outputs | 32 |
| Digital Output Type | Transistor (PNP Sourcing) |
| Output Current | 0.3 A per point |
| Permitted Output Voltage | 4.5 to 30 VDC |
| OFF/ON Delay Time | 0.1 to 1 ms |
| Current Consumption | 0.113 A (at 5 VDC) |
| Mounting Type | DIN Rail |
| Degree of Protection | IP20 |
| Dimensions (H x W x D) | 90 mm x 150 mm x 50 mm |
| Weight | 325 g |
Used to govern the intricate sequencing of pneumatic solenoids, diverter gates, and cutter blades in automated packaging equipment.
Eliminates synchronization lag by utilizing ultra-fast 0.1 to 1 ms transistor switching to actuate multiple valves precisely, ensuring accurate package sealing and cutting.
Drives extensive visual feedback networks, including Andon boards, stack lights, and audible alarms across large automated factory zones.
Consolidates wiring and drastically reduces control cabinet space requirements by providing 32 discrete low-power 24VDC output points from a single compact PLC expansion block.
Manages the activation of routing diverter arms, pushers, and small pilot relays across an intricate warehouse material handling system.
Allows centralized CP1-series PLCs to command an array of distributed 24VDC sorting mechanisms seamlessly without needing multiple standalone I/O slices.
