USD 211.80
24 VDC compact PLC CPU with 12 DC inputs, 8 relay outputs, 5K-step logic, USB programming, RTC, battery backup, and 1 expansion slot.
Compact Omron CP1L-series PLC CPU module with 24 VDC supply, 12 DC inputs, 8 relay outputs, 5K-step program capacity, 10K-word DM, USB programming port, RTC, battery backup, and one expansion I/O slot. The DC-powered L20 platform supports high-speed counter functions and is intended for small machine control applications requiring relay output flexibility and simple system expansion.
| Parameter | Value |
|---|---|
| Supply voltage | 24 VDC |
| Input type | DC |
| Number of digital inputs | 12 |
| Output type | Relay |
| Number of digital outputs | 8 |
| Program capacity | 5 K steps |
| Data memory capacity | 10 K words |
| Communication port(s) | USB |
| Number of USB ports | 1 |
| Number of Ethernet ports | 0 |
| Number of RS-232 ports | 0 |
| Number of RS-485 ports | 0 |
| Communication option(s) | Serial RS-232C, Serial RS-422, Serial RS-485 |
| Real-time clock | Yes |
| Battery backup | Yes |
| Number of expansion I/O units | 1 max. |
| Built-in I/O | 20 points |
| Max. number of I/O points | 60 |
| Operating voltage range | 20.4 to 26.4 VDC |
| Power consumption | 13 W max. |
| Logic execution time | 0.55 µs |
| High-speed counters | 4 inputs / 2 axes |
| High-speed counter frequency | 100 kHz single-phase; 50 kHz differential phases (4x) |
| Quick-response inputs | 6 points |
| Input pulse width (quick-response inputs) | 50 µs max. |
| Ambient operating temperature | 0 to 55 °C |
| Ambient humidity | 10% to 90% (no condensation) |
| Ambient operating environment | No corrosive gas |
| Ambient storage temperature | -20 to 75 °C (excluding battery) |
| Power holding time | 2 ms min. |
The 24 VDC supply, relay outputs, and 12 DC inputs suit compact conveyor or indexing stations that need direct interfacing to switches, sensors, and contactor loads.
Provides simple discrete machine control without requiring a larger PLC platform.
Eight relay outputs allow direct control of solenoids, lamps, and small actuators in packaging subsystems where output polarity or load type flexibility is useful.
Eliminates the need for external interposing relays in many low-power switching tasks.
The 4 high-speed counter inputs and 100 kHz single-phase capability make it suitable for pulse-based counting, encoder monitoring, or position-triggered inspection in small automation cells.
Accurately captures fast pulse events that standard PLC inputs can miss.
