USD 185.16
24 VDC compact PLC CPU with 6 inputs, 4 transistor outputs, 100 kHz counters, and 100 kHz pulse outputs.
Compact CP1L L-type CPU unit with DC supply, 10-point base I/O, transistor outputs, and built-in high-speed counter/pulse output capability. The official Omron datasheet lists the CP1L-L10DT-D as a 24 VDC control logic unit with 6 inputs and 4 transistor outputs, intended for compact machine control and motion-oriented automation tasks. It supports 100 kHz high-speed counters across 4 axes and 100 kHz pulse outputs on transistor-output models.
| Parameter | Value |
|---|---|
| Power supply voltage | 24 VDC |
| Built-in inputs | 6 |
| Built-in outputs | 4 transistor outputs |
| Output method | Transistor output (sourcing) |
| Memory capacity | 5K steps |
| High-speed counters | 100 kHz, 4 axes |
| Pulse outputs | 100 kHz, 2 axes |
| CPU unit type | CP1L-L CPU Unit with 10 Points |
| Weight | 300 g max. |
| Width | 56 mm |
| Height | 85 mm |
| Depth | 66 mm |
The 100 kHz pulse output and high-speed counter support precise position indexing for short conveyor moves and stop-and-go transfer stations.
Accurate position control in a compact PLC without a larger motion controller.
The 6 inputs and 4 transistor outputs fit compact start/stop, sensor, and actuator sequencing for tabletop or skid-mounted packaging equipment.
Controls small machines with limited I/O while keeping cabinet size and wiring low.
The transistor-output model can generate pulse trains at 100 kHz for low-axis-count motion tasks such as feeders, actuators, or label placement.
Provides direct pulse control for cost-sensitive motion applications.
