USD 146.81
AC-powered compact PLC CPU with 6 inputs, 4 relay outputs, USB programming, and 5K-step memory for small machine control.
AC-powered compact PLC CPU with 6 inputs, 4 relay outputs, USB programming, and 5K-step memory for small machine control.
| Parameter | Value |
|---|---|
| Power supply | 100 to 240 VAC, 50/60 Hz |
| Operating voltage range | 85 to 264 VAC |
| Inputs | 6 digital inputs |
| Outputs | 4 relay outputs |
| Memory capacity | 5K steps |
| Communications | USB |
| Mounting type | Chassis mount, DIN rail |
| Operating temperature | 0°C to 55°C |
| Weight | 300 g max. |
| Approximate bare product dimensions | 56 mm (W) x 85 mm (H) x 66 mm (D) |
| Physical Weight (kg) | 0.3 |
| Dimensions L x W x H (cm) | 6.6 x 5.6 x 8.5 |
Controls a small packaging station with discrete sensors and relay-actuated devices using the 6-input/4-output base and AC supply.
Provides simple on-machine sequencing without requiring a larger PLC platform.
Handles start/stop logic, permissives, and fault interlocks for a compact utility skid with low point count I/O.
Replaces hardwired relay logic with a programmable controller in a small control cabinet.
Manages sensors, stop/start signals, and simple actuator control for a short conveyor or indexing station in a compact footprint.
Delivers deterministic control for a low-axis, low-I/O machine at 100 to 240 VAC supply levels.
