USD 355.62
Ethernet PLC CPU, 18 DI/12 relay DO, 24 VDC supply, 10K-step program, 100 kHz counters, compact DIN-rail control
Compact CP1L CPU unit with built-in Ethernet, 10K-step program capacity, DC supply, relay outputs, and 18 digital inputs/12 relay outputs. The Omron datasheet identifies it as a CP1L-EM series CPU with high-speed counters to 100 kHz on 4 axes and pulse outputs to 100 kHz on 2 axes for transistor-output variants. Suitable for small machine control, networked automation, and relay-switched load control.
| Parameter | Value |
|---|---|
| CPU series | CP1L-EM |
| Model | CP1L-EM30DR-D |
| Power supply | DC power supply |
| Output method | Relay output |
| Inputs | 18 |
| Outputs | 12 |
| Program capacity | 10K steps |
| High-speed counters | 100 kHz, 4 axes |
| Pulse outputs | 100 kHz, 2 axes (models with transistor outputs only) |
| Built-in communication | Ethernet port |
| Mounting | DIN rail / chassis mount |
| Operating temperature | 0°C to 55°C |
| Memory size | 32K words |
| Battery backup | Supported |
| Approvals | CE |
| Unit weight | 610 g max. |
| Dimensions (W x H x D) | 110 mm x 85 mm x 130 mm |
Built-in Ethernet and 18/12 I/O make it suitable as the main controller for small packaging machines that need coordinated sensor, valve, and actuator control.
Eliminates the need for a separate communication module in compact machine panels while keeping relay-switched outputs for mixed loads.
The 100 kHz high-speed counter capability supports fast encoder or pulse input monitoring for conveyor indexing, reject gates, and position-related sequencing.
Provides reliable counting and timing for discrete motion-related tasks in small material-handling systems.
Relay outputs and DC supply suit compact pump or utility skids where discrete level switches, interlocks, and starter coils must be controlled from one CPU.
Consolidates interlock logic and direct relay switching in a small industrial control panel.
