USD 90.35
24 VDC compact PLC CPU with 6 DC inputs, 4 sourcing transistor outputs, USB, 2K/2K memory, 10 kHz input.
Compact CP-series CPU unit for 24 VDC automation systems with 10 built-in I/O points: 6 DC inputs and 4 sourcing transistor outputs. Official Omron product data identifies 2K steps of program memory, 2K words of data memory, USB communication, 10 kHz encoder input capability, and a 0–55 °C operating range. The product page also lists the bare product dimensions and weight, and indicates the model is planned for end of production on 2027-03-31.
| Parameter | Value |
|---|---|
| Supply voltage type | DC |
| Rated supply voltage | 24 VDC |
| Number of digital inputs | 6 |
| Input type | PNP/NPN |
| Number of digital outputs | 4 |
| Output type | PNP (sourcing transistor) |
| Program capacity | 2K steps |
| Data memory capacity | 2K words |
| Logic execution time | 1.19 µs |
| Communication port(s) | USB |
| Number of Ethernet ports | 0 |
| Number of USB ports | 1 |
| Number of RS-232 ports | 0 |
| Number of RS-485 ports | 0 |
| Communication option(s) | None |
| Max. encoder input frequency | 10 kHz |
| Max. number of PTP axes | 0 |
| Max. pulse output frequency | 0 kHz |
| Function Block programming | Not specified |
| Battery-free memory backup | Not specified |
| Real-time clock | Not specified |
| Analogue option boards | Not specified |
| Max. number of analogue I/O channels | 0 |
| Max. number of local I/O points | 10 |
| Max. number of expansion units | 0 |
| Built-in auxiliary 24 VDC output | 0 mA |
| Operating temperature range | 0–55 °C |
| Product height (unpacked) | 90 mm |
| Product width (unpacked) | 66 mm |
| Product depth (unpacked) | 85 mm |
| Product weight (unpacked) | 300 g |
Controls a small machine with 6 discrete sensors and 4 transistor outputs directly from a 24 VDC control supply.
Eliminates the need for a larger PLC when only a few fast DC I/O points are required in a compact panel.
Handles fast sensor feedback up to the published 10 kHz encoder input frequency for light motion or pulse-based detection tasks.
Provides dependable pulse capture for simple counting or indexing applications without adding separate high-speed hardware.
Fits retrofit projects where panel depth and footprint are constrained, using the published bare size of 90 × 66 × 85 mm.
Enables PLC replacement or upgrade in cabinets with limited mounting space while retaining standard 24 VDC wiring practices.
