USD 90.35
10-point compact PLC CPU, 24 VDC supply, sinking transistor outputs, 90 × 85 × 66 mm, 300 g max.
Compact CP-series PLC CPU unit with 10 I/O points and 24 VDC supply, designed for panel-mounted machine control. The CP1E-E10DT-D is the DC-power model in Omron’s CP1E family and is listed as a sinking transistor output unit. Manufacturer documentation shows a compact 90 mm × 85 mm × 66 mm enclosure with 300 g max weight, making it suitable for space-constrained control panels. Omron’s CP1E family targets simple automation with built-in control capability and expandability options.
| Parameter | Value |
|---|---|
| Supply voltage | 24 VDC |
| Operating voltage range | 20.4 to 26.4 VDC |
| Power consumption | 9 W max. |
| Inrush current | 30 A for 20 ms max. at cold start, room temperature |
| External power supply | Not provided |
| Enclosure | Mounted in a panel |
| Dimensions (H × D × W) | 90 mm × 85 mm × 66 mm |
| Weight | 300 g max. |
| Ambient operating temperature | 0 to 55 °C |
| Output type | Sinking transistor output |
A small conveyor or indexing station can be controlled from a compact 24 VDC PLC with sinking outputs, minimizing cabinet space while driving discrete loads and sensors.
Space-constrained discrete control with low-power panel integration.
A simple packaging machine with a limited number of inputs and outputs can use this CPU to manage sensors, actuators, and interlocks in a small enclosure.
Reliable sequencing for low-IO automation without oversized hardware.
Bench or fixture automation requiring low-voltage control and compact mounting can use the PLC to coordinate clamps, indicators, and presence sensors.
Integrated control for small test fixtures with minimal cabinet footprint.
