10-point 24 VDC PLC CPU with relay outputs, 2K-step program memory, 2K-word data memory, and compact 90 × 85 × 66 mm body.
Compact CP1E E-type CPU unit with 10 built-in I/O points and relay outputs, designed for 24 VDC power systems. Official Omron documentation identifies this model as a 6-input/4-output controller with 2K-step program capacity and 2K-word data memory, intended for small machine control and basic automation panels. The unit is part of the CP1E PLC family and is listed with a bare-unit weight of 280 g max. Omron also publishes the enclosure dimensions for the 10-point CP1E-E10D@-@ platform as 90 mm × 85 mm × 66 mm.
| Parameter | Value |
|---|---|
| Power supply | 24 VDC |
| Built-in I/O points | 10 total |
| Inputs | 6 |
| Outputs | 4 |
| Output type | Relay |
| Program capacity | 2K steps |
| Data memory capacity | 2K words |
| Current consumption (5 VDC) | 0.08 A |
| Current consumption (24 VDC) | 0.04 A |
| Dimensions (bare unit) | 90 mm × 85 mm × 66 mm |
| Weight (bare unit) | 280 g max |
Useful for small standalone machines needing a 24 VDC controller with a limited number of discrete sensors and actuators.
Provides simple on-machine control without requiring a larger PLC rack or external I/O expansion for basic logic.
Fits control panels that switch mixed field loads through relay contacts and need straightforward hardwired interfacing.
Relay outputs simplify interfacing with contactors, pilot devices, and legacy control circuits.
Appropriate for small conveyors, indexers, or handling stations with modest I/O counts and compact enclosure constraints.
Delivers PLC logic in a small footprint where panel space and controller size are constrained.
