1. Main Air Supply for Automotive Paint Shops
Deployed as the primary stage filtration unit at the entrance of automotive painting zones. The unit filters large volumes of compressed air required for paint robots and pneumatic atomizers, ensuring the removal of bulk contaminants like pipe scale and condensate before finer filtration stages.
Problem SolvedPrevents 'fisheye' and cratering defects in paint finishes caused by Paint-Wetting Impairment Substances (PWIS). The specific 'LABS/PWIS conformity (VDMA24364-B1/B2-L)' ensures the filter materials do not release silicones or contaminants that ruin paint adhesion, while the fully automatic drain eliminates the need for maintenance personnel to enter sensitive clean zones to empty bowls.
LABS/PWIS ConformityVDMA24364-B1/B2-LFully automatic condensate drainSize 9 High FlowISO 8573-1:2010 [6:8:4]
2. Bulk Nitrogen Gas Distribution Network
Installed as a high-flow particulate filter in centralized inert gas grids used for heat treatment furnaces or electronics inerting. The unit processes Nitrogen (N2) at pressures up to 12 bar, removing particulate matter generated from carbon steel piping networks before the gas reaches precision flow controllers.
Problem SolvedSolves the issue of valve seat erosion and clogging in downstream mass flow controllers caused by rust and dust in aging pipework. The 'Inert gases' compatibility and 'Wrought aluminium alloy' bowl provide the necessary safety and material compatibility for handling pressurized nitrogen in industrial environments where plastic bowls might degrade or pose safety risks.
Inert gas filtrationOperating pressure 2-12 barWrought aluminium alloy bowl5 µm filtrationCentrifugal separator
3. Semiconductor Sub-Fab Utility Air Prep
Utilized in the sub-fabrication level of semiconductor plants to filter general pneumatic air for tool actuation (e.g., wafer handling robots). The unit serves as the robust pre-filter stage, ensuring air quality meets the facility's background cleanliness requirements without frequent maintenance interventions.
Problem SolvedMaintains strict 'ISO Class 7' cleanroom compliance for the facility's air background level. The 'Fully automatic drain' is critical here as sub-fab areas are often cramped and hard to access for manual maintenance. The 5 µm pore size effectively protects downstream sterile filters (0.01 µm) from premature blinding by capturing 75% of condensate and coarse dust.
Cleanroom Class 7ISO 14644-1Fully automatic drainCondensate separation >75%Moderate corrosion stress CRC 2
