1. Precision Robotic Assembly Cell Air Preparation
Serves as the primary air preparation unit for a high-speed pick-and-place robotic cell, conditioning the compressed air supply before it reaches sensitive solenoid valve manifolds and pneumatic grippers.
Problem SolvedProtects miniature pilot valves and high-speed actuators from jamming due to fine dust (down to 5µm) while maintaining a stable operating pressure to ensure consistent gripping force and actuation speed during rapid cycles.
5 µm filtration grade4000 l/min nominal flowISO 8573-1:2010 [6:4:4] air purity0.5 - 12 bar regulation range
2. Automotive Assembly Line Pneumatic Tool Station
Regulates and filters air at a drop-leg station powering high-consumption handheld pneumatic tools, such as 1/2" impact wrenches and grinders, used in vehicle chassis assembly.
Problem SolvedPrevents premature wear of air motor vanes and internal bearings by filtering abrasive pipe scale and rust; delivers high volume air flow (up to 4000 l/min) through the G1/2 port to prevent pressure drops that cause under-torque events during fastening.
G1/2 pneumatic connection4000 l/min flow rateManual condensate drainDie-cast aluminium housing
3. Food Packaging Machine Control Cabinet Inlet
Installed at the main air inlet of a secondary packaging machine (e.g., cartoning or case packing) to regulate facility air down to machine working pressure and remove contaminants.
Problem SolvedEnsures 'Output pressure constant' to maintain precise timing of pneumatic cylinders despite fluctuations in the plant's main ring main; the 5µm filter provides the necessary air purity class to protect downstream vacuum generators and automation components in a wash-down compatible environment (CRC 2).
Output pressure constantCorrosion resistance class CRC 2Plastic bowl guard0.25 bar max pressure hysteresis
