This High Accuracy Height Gauge offers you the following benefits:
| Digital/Analog: |
Digital
|
| Range: |
0 – 600 mm
|
| Digital step: |
0,01/0,005 mm
|
| Max. Permissible Error E MPE: |
±0,05 mm
|
| Maximum Permissible Error J MPE: |
±0,05 mm
|
| Display: |
LCD, Character Height: 11 mm
|
| Max. response speed: |
500 mm/s
|
| ON/OFF: |
Yes
|
| ABS / INC (INC ZERO): |
Yes
|
| PRESET (2 values): |
Yes
|
| DATA (output with cable) / HOLD (display value): |
Yes
|
| Low voltage alarm: |
Yes
|
| ±SWITCHING: |
Yes
|
| Inch-Metric: |
Metric
|
| Delivered: |
Including scriber, scriber holder, 1 battery and cover
|
| Power supply: |
1 battery SR-44
|
| Battery life: |
approx. 3500 hours
|
| Mass: |
8.3 kg
|
All products of product family Series 192:
 |
Digital Height Gauge Double Column |
| 0-300mm | |
| Mitutoyo Digital Height Gauge Double Column Part Number: 192-613-10 | |
| More Info | |
 |
Digital Height Gauge Double Column |
| 0-1000mm | |
| Mitutoyo Digital Height Gauge Double Column Part Number: 192-615-10 | |
| For more : sales@inosaki.com | |
 |
Digital Height Gauge Double Column |
| 0-12″/300mm, Inch/Metric | |
| Mitutoyo Digital Height Gauge Double Column Part Number: 192-630-10 | |
| More Info | |
 |
Digital Height Gauge Double Column |
| 0-18″/450mm, Inch/Metric | |
| Mitutoyo Digital Height Gauge Double Column Part Number: 192-631-10 | |
| For more : sales@inosaki.com | |
 |
Digital Height Gauge Double Column |
| 0-24″/600mm, Inch/Metric | |
| Mitutoyo Digital Height Gauge Double Column Part Number: 192-632-10 | |
| More Info | |
 |
Digital Height Gauge Double Column |
| 0-40″/1000mm, Inch/Metric | |
| Mitutoyo Digital Height Gauge Double Column Part Number: 192-633-10 | |
| For more : sales@inosaki.com |
Optional accessories:
 |
Digimatic Cable, Flat Straight Type |
| 1m | |
| 905338 | |
| More Info | |
|
Digimatic Cable, Flat Straight Type |
| 2m | |
| 905409 | |
| For more : sales@inosaki.com | |
 |
USB Input Tool Direct (Digimatic USB) |
| Digi/Digi2, Flat Straight Type | |
| 06AFM380F | |
| More Info | |
 |
U-WAVE-T, Buzzer Type |
| Wireless Transmitter | |
| 02AZD880G | |
| For more : sales@inosaki.com | |
 |
U-WAVE-T, IP67 Type |
| Wireless Transmitter | |
| 02AZD730G | |
| For more : sales@inosaki.com | |
 |
U-WAVE-T Connection Cable F |
| Flat Straight Type | |
| 02AZD790F | |
| For more : sales@inosaki.com | |
 |
Holding Bar for Swivel Clamp |
| 9x9mm, 50mm Length | |
| 953638 | |
| For more : sales@inosaki.com | |
 |
Holding Bar for Swivel Clamp |
| 9x9mm, 100mm Length | |
| 900209 | |
| For more : sales@inosaki.com | |
 |
Swivel Clamp |
| for D=4/8mm, Dovetail | |
| 900321 | |
| For more : sales@inosaki.com | |
 |
Center Master |
| for 9x9mm | |
| 951144 | |
| For more : sales@inosaki.com | |
 |
Depth Gauge Attachment |
| for 9×9 mm | |
| 900764 | |
| For more : sales@inosaki.com |
Standard accessories:
 |
Scriber Clamp |
| for 9x9mm Scriber | |
| 05GZA033 | |
| For more : sales@inosaki.com | |
 |
Carbide Tipped Scriber |
| 9x9mm, 80mm Length | |
| 07GZA000 | |
| For more : sales@inosaki.com | |
 |
Vinyl Cover Series 192 |
| 300mm | |
| 450291 | |
| For more : sales@inosaki.com |
| Weight | 8.3 kg |
|---|
