Original price was: $ 321.08.$ 276.00Current price is: $ 276.00.
Mitutoyo 543-791B-10 Digital Indicator ID-S with ABSOLUTE sensor, 12.7mm/0.5″ range, 0.001mm resolution, IP42 protection, and long battery life.
The Mitutoyo 543-791B-10 Digital Indicator ID-S is a precision measuring tool designed for reliable and user-friendly operation in industrial environments. Featuring an ABSOLUTE electrostatic capacitance linear encoder, it eliminates the need for repeated origin setting, saving time and ensuring consistent results. With a measurement range of 0.5”/12.7 mm, resolution of 0.001 mm, and a large 9 mm LCD display, it provides both accuracy and excellent readability. Its robust IP42 protection and long battery life make it ideal for continuous use in demanding applications.
The Mitutoyo 543-791B-10 ID-S Digital Indicator combines precision engineering with ease of use. It offers a measuring range of 12.7 mm (0.5”), a fine resolution of 0.001 mm (0.00005”), and repeatability within 0.0001”/0.002 mm. The indicator is lightweight at 140 g, equipped with a carbide ball contact point, and powered by a single SR44 battery providing up to 18,000–20,000 hours of operation. Its LCD display with 9 mm characters ensures excellent visibility, while switchable inch/metric functions, ORIGIN (ABS-Zero) setting, and error alarms provide convenience and reliability in all professional settings.
The Mitutoyo 543-791B-10 is designed for professionals who demand accuracy, durability, and ease of use in measurement. Its ABSOLUTE sensor saves time by remembering zero settings, and the large display enhances productivity by reducing operator error. With seamless inch/metric switching and compatibility with data output systems, it becomes a versatile tool for workshops, laboratories, and production lines. Choosing this model means choosing a blend of Japanese precision and practical usability.
In many measurement tasks, re-zeroing indicators or misreading small displays can cause errors, wasted time, and inconsistent results. The Mitutoyo 543-791B-10 solves these problems with its ABSOLUTE encoder technology, ensuring reliable reference points without re-calibration at power-on. Its large, clear LCD display improves readability, while its long-lasting battery minimizes downtime. For engineers, machinists, and inspectors, this indicator ensures efficiency, accuracy, and confidence in every measurement task.
During machine setup, operators use the ID‑S to zero fixtures, verify tool offsets, and check part height without re‑zeroing between power cycles. The ABSOLUTE encoder preserves origin, cutting setup time and preventing drift. The 0.001 mm resolution and large 9 mm LCD make pass/fail calls quick on the shop floor. With gentle measuring force and fast response, repeat checks on the same reference surface stay consistent across shifts.
On assembly lines, the indicator monitors press‑fit depth, actuator stroke, or stack‑up thickness inside jigs. IP42 protection tolerates light dust and coolant mist, while long battery life supports multi‑shift operation. Inch/metric switching speeds mixed‑drawing environments, and repeatability supports SPC sampling. The clear display reduces reading errors for technicians moving between stations, and data output enables logging trends to catch drift before it becomes rework.
Quality teams measure shims, spacers, and turned parts to confirm supplier tolerances at goods‑in. The carbide contact resists wear during repeated checks, and the ≤1.5 N measuring force helps protect delicate finishes. The ABS‑zero function keeps a stable reference across multiple lots, while the 12.7 mm range covers common small components. Optional data capture accessories allow quick recording of min/max values to document compliance and drive supplier feedback.
In lab setups, engineers validate small displacements—spring deflection, cam profiles, or fixture repeatability. The indicator’s 0.001 mm resolution and smooth response help map movement curves without missed peaks. ABS origin simplifies baseline comparisons over long tests or after power cycling. With data output, teams stream readings to analysis software, correlate displacement with force or temperature, and build traceable reports for design reviews and process capability studies.
| Feature | Details | Benefit |
|---|---|---|
| Measuring Range | 0.5″ / 12.7 mm | Covers a wide variety of dimensional inspection tasks. |
| Resolution | 0.00005″ / 0.001 mm | Ensures ultra-precise readings for demanding applications. |
| Max. Permissible Error (E MPE) | ±0.0001″ / 0.003 mm | Delivers consistent and accurate measurements you can trust. |
| Hysteresis (H MPE) | 0.0001″ / 0.002 mm | Reduces variation between repeated measurements. |
| Repeatability (R MPE) | 0.0001″ / 0.002 mm | Guarantees stable results across multiple checks. |
| Measuring Force | ≤1.5 N | Gentle contact avoids damaging delicate surfaces. |
| Display | LCD, 9 mm character height | Large, clear digits reduce operator errors and eye strain. |
| Digital Scale Type | ABSOLUTE electrostatic capacitance linear encoder | Eliminates the need for re-zeroing at startup, saving time. |
| Functions | ON/OFF, ORIGIN (ABS-Zero), Inch/Metric switchable, Counting direction switchable | Flexible operation for different measurement requirements. |
| Data Output | Yes (requires optional cable/software) | Enables easy transfer to SPC systems or PCs. |
| Protection Rating | IP42 | Safeguards against dust and light water spray, suitable for workshop use. |
| Power Supply | 1 × SR44 battery | Compact and reliable power source. |
| Battery Life | ~18,000 hrs (0.001 mm type) / ~20,000 hrs (0.01 mm type) | Long operating time minimizes downtime and battery changes. |
| Stem Diameter | 8 mm | Fits standard fixtures and stands easily. |
| Contact Point | Carbide ball, M2.5 × 0.45 thread | Durable and wear-resistant for repeated use. |
| Mass | 140 g | Lightweight, easy to handle or mount on jigs. |
| Max. Response Speed | Unlimited | Captures fast movements without missing readings. |
| Alarm Functions | Low battery, sensor error, ABS data composition error | Alerts users to prevent inaccurate readings. |
| Compliance | EN ISO Standard | Assures international quality and measurement standards. |
All products of product family Series 543:
 |
Digital Indicator ID-S |
| 12,7mm, 0,001mm, Flat Back Plate | |
| 543-790B-10 | |
| More Info | |
 |
Digital Indicator ID-S |
| 12,7mm, 0,001mm, Flat Back Plate | |
| 543-791B-10 | |
| More Info | |
 |
Digital Indicator ID-S
|
| 12,7mm, 0,01mm, Flat Back Plate | |
| 543-781B-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S |
| 12,7mm, 0,01mm, Lug Back Plate | |
| 543-781-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S |
| 12,7mm, 0,001mm, Lug Back Plate | |
| 543-790-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, IP53 |
| 12,7mm, 0,001mm, Flat Back Plate | |
| 543-794B-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, IP53 |
| 12,7mm, 0,001mm, Lug Back Plate | |
| 543-794-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S |
| Inch/Metric, 0,5″, 0,0005″, Flat Back Plate | |
| 543-782B-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S |
| Inch/Metric, 0,5″, 0,0005″, Lug Back Plate | |
| 543-782-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S |
| Inch/Metric, 0,5″, 0,00005″, Lug Back Plate | |
| 543-791-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, IP53 |
| Inch/Metric, 0,5″, 0,00005″, Lug Back Plate | |
| 543-795B-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, IP53 |
| Inch/Metric, 0,5″, 0,00005″, Lug Back Plate | |
| 543-795-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, ASME/ANSI Type
|
| Inch/Metric, 0,5″, 0,0005″, Flat Back Plate | |
| 543-783B-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, ASME/ANSI Type |
| Inch/Metric, 0,5″, 0,0005″, Lug Back Plate | |
| 543-783-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, ASME/ANSI Type |
| Inch/Metric, 0,5″, 0,0001″, Flat Back Plate | |
| 543-793B-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, ASME/ANSI Type |
| Inch/Metric, 0,5″, 0,0001″, Lug Back Plate | |
| 543-793-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, ANSI/AGD |
| Inch/Metric, 0,5″, 0,00005″, Lug Back Plate | |
| 543-792-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, ASME/ANSI Type |
| Inch/Metric, 0,5″, 0,00005″, Flat Back Plate | |
| 543-792B-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, IP53 |
| ASME/ANSI Type, Inch/Metric, 0,5″, 0,00005″, Lug Back Plate | |
| 543-796-10 | |
| For more : Contact us | |
 |
Digital Indicator ID-S, IP53 |
| ASME/ANSI Type, Inch/Metric, 0,5″, 0,00005″, Lug Back Plate | |
| 543-796B-10 | |
| For more : Contact us |
Optional accessories:
 |
Air Drive Unit, Indicator/Linear Gauge |
| for ID-S, ID-C, LGS, 12,7 mm and 0,5” Range | |
| Mitutoyo Part Number : 903594 | |
| For more : Contact us | |
 |
Digimatic Cable, Flat Straight Type |
| 1 m | |
| Mitutoyo Part Number : 905338 | |
| For more : Contact us | |
 |
Digimatic Cable, Flat Straight Type |
| 2 m | |
| Mitutoyo Part Number : 905409 | |
| For more : Contact us | |
 |
USB Input Tool Direct (Digimatic to USB) |
| 2m Cable, Digimatic/Digimatic 2, Flat Straight Type | |
| Mitutoyo Part Number : 06AFM380F | |
| For more : Contact us | |
 |
USB Input Tool Interface Box |
| Digimatic/Digimatic 2/Digimatic S1 Interface | |
| Mitutoyo Part Number : 264-020 | |
| For more : Contact us | |
 |
U-WAVE-T, Buzzer Type |
| Wireless Transmitter | |
| Mitutoyo Part Number : 02AZD880G | |
| For more : Contact us | |
 |
U-WAVE-T, IP67 Type |
| Wireless Transmitter | |
| Mitutoyo Part Number : 02AZD730G | |
| For more : Contact us | |
 |
U-WAVE fit, IP67 Type |
| Wireless Transmitter for Micrometer/Indicator | |
| Mitutoyo Part Number : 264-622 | |
| For more : Contact us | |
 |
U-WAVE fit, Buzzer Type |
| Wireless Transmitter for Micrometer/Indicator | |
| Mitutoyo Part Number : 264-623 | |
| For more : Contact us | |
 |
U-WAVE fit Bluetooth, IP67 Type |
| Wireless Transmitter for Micrometer/Indicator | |
| Mitutoyo Part Number : 264-626 | |
| For more : Contact us | |
 |
U-WAVE fit Bluetooth, Buzzer Type |
| Wireless Transmitter for Micrometer/Indicator | |
| Mitutoyo Part Number : 264-627 | |
| For more : Contact us | |
 |
Connection Cable F for U-WAVE
|
| Straight, without Data Button | |
| Mitutoyo Part Number : 02AZD790F | |
| For more : Contact us | |
 |
U-WAVE Transmitter Mounting Plate |
| Universal Type | |
| Mitutoyo Part Number : 02AZE200 | |
| For more : Contact us | |
 |
U-WAVE fit Transmitter Mounting Plate |
| for ID-C, ID-S and ID-F Digital Indicator | |
| Mitutoyo Part Number : 02AZF670 | |
| For more : Contact us | |
 |
Spindle Lifting Lever |
| for Digital Indicator, A-Type Dial Indicator Serie 2/3/4 | |
| Mitutoyo Part Number : 21EZA198 | |
| For more : Contact us | |
 |
Spindle Lifting Cable |
| for Indicator, L=500mm | |
| Mitutoyo Part Number : 21JZA295 | |
| For more : Contact us | |
 |
Spindle Lifting Cable with Auto Stop |
| for Indicator, L=300mm | |
| Mitutoyo Part Number : 21JZA301 | |
| For more : Contact us | |
 |
Spindle Lifting Knob |
| for 12,7mm Range | |
| Mitutoyo Part Number : 21EZA105 | |
| For more : Contact us |
Consumable spares:
 |
Battery SR44 1.5V |
| Mitutoyo Part Number: 938882 | |
| For more : Contact us | |
 |
Contact Element Ball Point, M2,5×0,45 |
| 7,3mm Length, Carbide, Metric | |
| Mitutoyo Part Number: 901312 | |
| For more : Contact us |
