Part Number: 1076656
Inductive proximity Sensor Model: IMF30-15BPPNC0S
OEM Spec Ref
Features
| Housing |
Cylindrical thread design |
| Housing |
Standard |
| Thread size |
M30 x 1.5 |
| Diameter |
Ø 30 mm |
| Sensing range Sn |
15 mm |
| Safe sensing range Sa |
12.15 mm |
| Installation type |
Flush |
| Switching frequency |
500 Hz |
| Connection type |
Male connector M12, 4-pin 1) |
| Switching output |
PNP |
| Output function |
Complementary |
| Electrical wiring |
DC 4-wire |
| Enclosure rating |
IP68 2)
IP69K 3) |
| Special features |
Resistant to cleaning agents, IO-Link, Temperature resistance |
| Special applications |
Hygienic and washdown zones, Difficult application conditions |
Mechanics/electronics
| Supply voltage |
10 V DC … 30 V DC |
| Ripple |
≤ 10 % |
| Voltage drop |
≤ 2 V 1) |
| Current consumption |
10 mA 2) |
| Hysteresis |
3 % … 20 % |
| Reproducibility |
≤ 2 % 3) 4) |
| Temperature drift (of Sr) |
± 10 % |
| EMC |
According to EN 60947-5-2 |
| Continuous current Ia |
≤ 200 mA |
| Short-circuit protection |
✔ |
| Reverse polarity protection |
✔ |
| Power-up pulse protection |
✔ |
| Power-up pulse |
≤ 5 ms |
| Shock and vibration resistance |
100 g / 2 ms / 500 cycles; 150 g / 1 Mio cycles; 10 Hz … 55 Hz / 1 mm; 55 Hz … 500 Hz / 60 g |
| Ambient operating temperature |
–40 °C … +100 °C |
| Housing material |
Stainless steel V4A, DIN 1.4404 / AISI 316L |
| Sensing face material |
Plastic, LCP |
| Housing length |
70 mm |
| Thread length |
52 mm |
| Tightening torque, max. |
Typ. 100 Nm |
| Items supplied |
Mounting nut, V4A stainless steel (2x) |
| Protection class |
III |
| UL File No. |
E181493 |
Safety-related parameters
| MTTFD |
1,687 years |
| DCavg |
0 % |
| TM (mission time) |
20 years |
