Part Number: 6021124
Inductive proximity Sensor Model: IM12-02B-N-ZW0
OEM Spec Ref
Features
| Housing |
Cylindrical thread design |
| Thread size |
M12 x 1 |
| Diameter |
Ø 12 mm |
| Sensing range Sn |
2 mm |
| Safe sensing range Sa |
1.62 mm |
| Installation type |
Flush |
| Switching frequency |
1,200 Hz |
| Connection type |
Cable, 2-wire, 2 m |
| Switching output |
NAMUR |
| Output function |
NC |
| Enclosure rating |
IP67 1) |
| Special applications |
Explosive areas |
Mechanics/electronics
| Supply voltage |
7.5 V DC … 25 V DC 1) |
| Current consumption |
30 mA 1) |
| Hysteresis |
1 % … 15 % |
| Temperature drift (of Sr) |
± 10 % |
| EMC |
According to EN 60947-5-6 |
| Current consumption, sensor is activated |
≤ 1 mA |
| Current consumption, sensor is not activated |
≥ 2.2 mA |
| Cable material |
PVC |
| Conductor size |
0.34 mm² |
| Cable diameter |
Ø 4.9 mm |
| Cable resistance |
50 Ω |
| Shock and vibration resistance |
30 g, 11 ms / 10 … 55 Hz, 1 mm |
| Ambient operating temperature |
–20 °C … +70 °C |
| Housing material |
Brass, nickel-plated |
| Sensing face material |
Plastic, PTB |
| Housing length |
30 mm |
| Thread length |
29 mm |
| Tightening torque, max. |
7 Nm |
| Weight |
+ 130 g |
| Items supplied |
Mounting nut, brass, nickel-plated (2x) |
| Type approval certificate |
PTB 03 ATEX 2037 |
| Ex area category |
1G |
| Input voltage Ui max. |
15 V 2) |
| Input power Pi max. |
120 mW 2) |
| Input current Ii max. |
50 mA 2) |
| Internal capacitance Ci max. |
140 nF 2) |
| Internal inductance Li max. |
340 µH 2) |
| Nominal voltage |
8.2 V DC 3) |
| Device labeling |
II 1G Ex ia IIC T6 Ga Ta –20 °C … +70 °C |
