$ 311.19
High-resolution 8 MP GigE Vision camera with Sony IMX678 sensor, compact design, and robust performance for industrial automation and inspection.
The IDS Imaging GV-54J4LE Rev.2 is a compact, industrial-grade camera series offered in both monochrome (M-GL) and color (C-HQ) models. Built around the advanced Sony IMX678 rolling shutter CMOS sensor, it delivers an 8.39 MP resolution (3856 × 2176) with a wide 16:9 format, ensuring sharp and detailed imaging. Its GigE Vision® interface enables reliable, high-speed data transmission over long distances, while its efficient power use and broad operating temperature tolerance make it suitable for demanding automation, inspection, and embedded vision environments. Designed for longevity, it is a dependable choice for projects requiring consistent and precise image capture.
With a compact 50 × 50 × 32 mm form factor, the GV-54J4LE Rev.2 offers high pixel density with 2 µm pixels for exceptional image clarity. The monochrome version provides excellent contrast for measurement tasks, while the color model ensures accurate tone reproduction for applications where color fidelity is critical. Features such as hardware and software triggering, extended exposure times up to nearly 120 seconds, and on-camera image processing options like denoising, ROI, and decimation help optimize performance. Its GigE RJ45 interface simplifies integration into existing systems, and the wide 12–24 V power range adds installation flexibility. Engineered for durability, it meets the needs of industrial imaging where reliability and precision are essential.
The GV-54J4LE Rev.2 combines the precision of an 8 MP Sony IMX678 sensor with the reliability of GigE Vision connectivity in a compact, lightweight form. It’s designed for projects where every pixel counts—whether capturing microscopic detail, ensuring measurement accuracy, or producing vibrant, true-to-life colors. With long-term availability, it’s a future-proof investment for industrial vision systems.
This camera tackles the challenge of achieving high-resolution, stable imaging in tough industrial settings without sacrificing speed or flexibility. It delivers detailed images over long cable runs, supports extended exposures for low-light scenes, and integrates easily into existing networks. For manufacturers, inspectors, and automation engineers, it means dependable, accurate results—shot after shot, shift after shift.
| Feature | Details | Benefit |
|---|---|---|
| Sensor Brand & Model | Sony IMX678 CMOS (Color: IMX678-AAQR1-C, Mono: IMX678-AAMR1-C) | High sensitivity and low noise for sharp, detailed images. |
| Interface | GigE Vision® over RJ45 | Reliable long-distance data transfer with standard Ethernet infrastructure. |
| Interface Speed | Up to 1 Gbps | Supports high data throughput for full-resolution capture. |
| Resolution (HxV) | 3856 × 2176 (8.39 MP) | Captures fine details for precision inspection and measurement. |
| Optical Area (HxV) | 7.712 mm × 4.352 mm | Large active area for enhanced light collection. |
| Optical Format | 1/1.8″ (Diagonal 8.86 mm) | Industry-standard format for lens compatibility. |
| Lens Mount | C-Mount | Supports a wide range of industrial and scientific lenses. |
| Pixel Size | 2 µm | High pixel density for sharp, detailed imaging. |
| Image Memory | Via host PC (IDS peak software) | Flexible storage and image handling for diverse applications. |
| Frame Rate @ Max. Resolution | 14 fps (freerun/trigger), up to 17 fps (max trigger) | Maintains performance in both continuous and triggered modes. |
| Shutter | Rolling shutter | Delivers smooth motion capture with high resolution. |
| Exposure Time | 0.026 ms – 1999 ms (up to 119.978 s long exposure) | Handles both high-speed and low-light imaging scenarios. |
| Trigger & Flash I/O | GPIO lines, 3.3 V trigger input, flash output | Supports synchronized imaging and strobe lighting control. |
| Power Supply | 12–24 V DC | Flexible power integration for various system designs. |
| Software Tools | IDS peak SDK, on-camera denoising, ROI, decimation, binning | Optimizes performance and simplifies system integration. |
| Environmental Tolerance | Operating: 0°C to 40°C; Storage: -20°C to 60°C; Humidity: 20–80% non-condensing | Reliable operation in diverse industrial environments. |
| Housing Protection | Not rated (IP code –) | Suitable for controlled environments; can be enclosed for added protection. |
| Size & Weight | 50 × 50 × 32 mm, 35 g | Compact and lightweight for easy system integration. |
Download GV-54J4LE-C-HQ Rev.2 (1011650) Datasheet
Download GV-54J4LE-M-GL Rev.2 (1011653) Datasheet
Download GV-54J4LE Rev.2 Technical Drawing
Security systems often face inconsistent lighting—shadows at dawn, glare at dusk, and patchy illumination at night. The 8 MP IMX678 sensor handles these challenges with strong visible and near-infrared sensitivity, delivering detailed, low-noise images even under minimal lighting. Its 16:9 format covers large areas while retaining the fine detail needed for identifying people or vehicles. Combined with GigE Vision connectivity, it allows stable streaming over long cable runs, making it ideal for large industrial sites, storage yards, and campus perimeter systems that operate around the clock.
High-resolution planetary imaging demands sensors that balance fine detail capture with low noise. The IMX678’s 2 µm pixels and excellent quantum efficiency make it a favorite for lunar and planetary observation, revealing intricate features such as crater edges and atmospheric bands. It supports fast frame capture for “lucky imaging” techniques and can extend exposure times to record faint details. While this performance benefits astronomy, the same traits apply to industrial uses where high-contrast detail in small objects is crucial, such as quality control in precision manufacturing.
In busy warehouses, mobile robots rely on vision systems to navigate and identify objects under varying light sources. The IMX678 sensor maintains clear texture and barcode definition, even in dim aisles or under mixed lighting. Its compact form factor and efficient power use suit embedded computing platforms, enabling onboard object detection and path planning without additional lighting infrastructure. This results in smoother navigation, fewer errors in product handling, and improved efficiency for logistics operations where downtime can be costly.
Traffic and parking environments present extreme lighting variations—from bright sunlight to nighttime headlights. The IMX678 delivers consistent image clarity in these conditions, aided by its ability to capture in both visible and near-infrared light. For traffic systems, the 8 MP resolution ensures accurate vehicle classification, lane detection, and license plate recognition. In parking structures, it enables precise occupancy tracking and improved security monitoring. Its compatibility with standard interfaces makes it easy to integrate into existing intelligent transportation and parking management solutions.
Retail environments and biometric systems demand both fine detail capture and adaptability to shifting lighting conditions. The IMX678 sensor excels here, preserving texture in packaging, shelf labels, and facial features without requiring excessive illumination. Its sensitivity in both visible and NIR ranges supports privacy-conscious biometric authentication and nighttime operation without harsh lighting. When combined with embedded processors, these cameras can deliver on-device analytics—enabling real-time queue monitoring, inventory checks, and customer flow analysis while reducing network load.
IDS Accessories (Recommended)
C-Mount Lenses (IDS Approved) – Optimized for 1/1.8″ sensors
GigE Hubs and Cables – For multi-camera synchronization setups
GPIO Interface Boards – For trigger and flash signal integration
Industrial Camera Mounts – For stable positioning in machine vision systems
IDS Imaging Cameras
U3-3800CP Series – 8 MP Sony IMX183 USB3 Camera
GV-51A2SE Series – 3.2 MP Sony IMX265 GigE Camera
As an authorized distributor of IDS Imaging products, we offer certified expertise and technical support to ensure you get the most out of your IDS Imaging GV-54J4LE Rev.2 – 8 MP camera. We stand by the quality of our products and provide comprehensive warranty services. Our team can also assist with special services like custom integration and creating pre-configured kits tailored to your specific needs.
We also offer:
Custom integration services for embedded systems
Pre-configured vision kits tailored to your project requirements
