IDS GV-53F2LE 5 MP global shutter GigE camera with Sony IMX568 delivers blur-free imaging up to 34 fps for fast, precise inspection, robotics, and QA.
The IDS Imaging GV-53F2LE is a compact 5 MP industrial camera featuring the Sony IMX568 global shutter CMOS sensor, delivering precise image capture with minimal motion blur. Supporting a resolution of 2472 × 2064 pixels and GigE Vision interface, it offers seamless integration into high-speed inspection systems. Its 2.74 µm pixel size and high sensitivity ensure excellent image quality in both color (GV-53F2LE-C) and monochrome (GV-53F2LE-M) versions. Designed for demanding machine vision applications, the camera provides consistent performance with up to 34 fps in triggered mode, making it ideal for automation, robotics, and quality assurance environments.
Built for precision and reliability, the GV-53F2LE series combines the performance of Sony’s advanced IMX568 sensor with IDS’s robust GigE platform. The global shutter architecture captures fast-moving objects without distortion, while a wide operating temperature range supports use in challenging industrial conditions. Its compact 45 × 45 × 15 mm form factor fits into space-restricted systems, and flexible 12–24 V power input ensures easy deployment. Engineers benefit from adjustable region of interest, hardware/software triggering, and onboard image preprocessing for reduced host load. This makes the GV-53F2LE an optimal choice for applications such as electronics inspection, packaging verification, and automated optical measurement.
Why IDS Imaging GV-53F2LE?
Because it delivers crystal-clear, distortion-free images at high speed, even in challenging industrial environments, thanks to its Sony IMX568 global shutter sensor and GigE Vision reliability.
What problem does it solve?
The GV-53F2LE tackles the challenge of capturing sharp, accurate images of fast-moving objects in automation and inspection tasks. By eliminating motion blur and ensuring consistent image quality, it enables engineers to detect defects, verify precision, and maintain production quality without slowing down operations.
| Feature | Details | Benefit |
|---|---|---|
| Sensor Brand & Model | Sony IMX568 (Global Shutter, CMOS – Color: IMX568-AAQJ-C, Mono: IMX568-AAMJ-C) | High sensitivity with minimal motion blur, ideal for high-speed imaging. |
| Interface | GigE Vision (RJ45) | Long cable runs up to 100 m, easy integration into existing networks. |
| Interface Speed | 1 Gbps | Reliable high-speed image transfer without frame drops. |
| Resolution (HxV) | 2472 × 2064 pixels (5.10 MP) | Captures fine detail for precision inspection and measurement. |
| Optical Area (HxV) | 6.708 mm × 5.612 mm | Optimized field of view for varied lens options. |
| Optical Format | 1/1.8″ (Diagonal 8.75 mm) | Compatible with a wide range of industrial lenses. |
| Lens Mount | – (Board-level, adaptable via accessories) | Flexible lens selection for custom applications. |
| Pixel Size | 2.74 µm | Sharp, detailed images even in low-light conditions. |
| Image Memory | – (Image processing handled via IDS Peak software) | Reduces system load and ensures efficient workflow. |
| Frame Rate @ Max. Resolution | 24 fps (freerun), up to 34 fps (triggered) | Smooth capture for high-speed production lines. |
| Shutter | Global Shutter | Eliminates rolling artifacts for moving objects. |
| Exposure Time | 0.013 ms – 2000 ms | Supports both ultra-fast and long-exposure imaging. |
| Trigger & Flash I/O | 1× trigger input, 1× flash output, 2× GPIO, I²C | Enables precise synchronization with external devices. |
| Power Supply | 12–24 V DC | Flexible power options for industrial integration. |
| Software Tools | IDS Peak SDK support | Seamless camera control, image acquisition, and preprocessing. |
| Environmental Tolerance | Operating: 0 °C – 30 °C; Device: up to 85 °C; Humidity: 20–80% non-condensing | Reliable operation in varied industrial environments. |
| Housing Protection | – (open-board design) | Designed for integration into custom enclosures. |
| Size & Weight | 45 × 45 × 15 mm, 15 g | Compact and lightweight for space-constrained systems. |
Download GV-53F2LE-C Datasheet
Download GV-53F2LE-M Datasheet
Download GV-53F2LE Technical Drawing
1) High-Speed Electronics Inspection
On fast-moving SMT lines, tiny components can pass inspection points in milliseconds, making image clarity critical. The 5 MP IMX568 global shutter sensor freezes motion without distortion, ensuring solder joints, leads, and fine PCB traces are sharply visible. With its 2.74 µm pixel size, short exposures can be used under bright industrial lighting, avoiding overexposure. The camera’s precise trigger and flash synchronization ensure every frame is perfectly timed, while GigE connectivity supports long-distance cabling across production lines. This combination allows manufacturers to maintain high throughput while improving defect detection and reducing costly rework.
2) Traffic & ANPR (Automatic Number Plate Recognition)
Highway monitoring systems require accurate plate capture at various speeds and lighting conditions. The IMX568’s global shutter eliminates motion blur at high speeds, and its high sensitivity enables short exposures in low light. The 5 MP resolution covers multiple lanes in a single frame, providing ample detail for OCR and vehicle classification. Using hardware triggering, captures are precisely aligned with passing vehicles, ensuring consistent recognition accuracy. This allows traffic enforcement and tolling systems to maintain reliability in all weather and lighting scenarios, reducing missed reads and false positives.
3) Collaborative Robotics & Bin-Picking
In robotic pick-and-place tasks, undistorted images are vital for accurate object localization. The IMX568 sensor’s global shutter ensures moving objects and grippers are captured sharply, supporting precise feature recognition. Its 5:4 aspect ratio and high pixel count provide detailed imagery for accurate depth calculations and pose estimation. Compact camera designs based on this sensor can be mounted close to robotic end-effectors, with GigE or PoE simplifying cabling. Synchronization with robot movements reduces errors, while fast exposure adjustments manage glare from task lighting, improving pick accuracy and cycle consistency.
4) Embedded Vision in Production Tools
For machine builders and OEMs, space-saving vision solutions are essential. The IMX568 enables compact camera designs that fit inside inspection heads or retrofit housings while still delivering industrial-grade performance. Engineers can fine-tune gain and exposure for reflective surfaces, use region of interest to boost frame rates, and integrate easily with existing software. The global shutter ensures precise edge definition for measurement tasks, making it suitable for automated optical inspection, dimensional verification, and quality control in high-precision manufacturing environments.
5) Warehouse Sortation & Code Reading
In high-speed logistics operations, packages move unpredictably and labels can shift or wrinkle. The IMX568’s global shutter captures barcodes and text without motion distortion, even on fast conveyors. Its 5 MP resolution allows wide coverage for scanning multiple chutes with a single camera. Short exposure settings help combat motion blur, while hardware-triggered capture aligns images with passing items for reliable decoding. The combination of speed, clarity, and broad field of view improves first-pass read rates, reducing manual intervention and keeping throughput high.
IDS Accessories (Recommended)
C-Mount Lenses (IDS Approved) – Optimized for 1/1.8″ sensors
GigE Hubs and Cables – For multi-camera synchronization setups
GPIO Interface Boards – For trigger/flash control with easy breakout access
IDS Imaging Cameras
GV-53F2LE-C – 5 MP Color Sony IMX568 GigE Camera
GV-53F2LE-M – 5 MP Mono Sony IMX568 GigE Camera
GV-51A2SE Series – 3.2 MP Sony IMX265 GigE Camera
GV-59F0CP Series – 12 MP Sony IMX545 GigE Camera
As an authorized distributor of IDS Imaging products, we offer certified expertise and technical support to ensure you get the most out of your IDS Imaging GV-53F2LE camera. We stand by the quality of our products and provide comprehensive warranty services. Our team can also assist with special services like custom integration and creating pre-configured kits tailored to your specific needs.
We also offer:
Custom integration services for embedded systems
Pre-configured vision kits tailored to your project requirements
