Original price was: $ 410.55.$ 315.79Current price is: $ 315.79.
Compact 3.2 MP IDS GigE Vision camera with Sony IMX900 global shutter, high-speed imaging, and S-Mount design for precision industrial applications.
The IDS GV-53D1LE-MB Rev.2 is a high-performance industrial camera series available in both color (C) and monochrome (M) variants, featuring Sony’s IMX900 global shutter CMOS sensor for exceptional image clarity. Designed for demanding machine vision and embedded system applications, it delivers a 3.20 MP resolution (2064 × 1552) with a compact 50 × 50 × 23.5 mm S-Mount design. Offering precise imaging at up to 73 fps in triggered mode, it excels in scenarios where sharp capture of fast-moving objects is essential. With low power consumption, flexible 12–24 V input, and robust operating temperature tolerance, it ensures reliable performance in space-constrained and thermally challenging environments.
Built for engineers who need uncompromising image quality in a minimal footprint, the GV-53D1LE-MB Rev.2 combines Sony’s advanced 2.25 µm pixel technology with IDS’s proven GigE Vision platform. The global shutter design eliminates motion blur, enabling accurate measurements in industrial inspection, robotics, and high-speed assembly lines. The color model ensures vibrant, true-to-life reproduction for surface inspection and quality control, while the monochrome variant excels in precision contrast detection and low-light applications. Its 37–73 fps capability supports time-critical processes, and with S-Mount lens compatibility, integration is quick and cost-efficient. The camera’s durability and extended temperature range make it ideal for continuous operation in demanding production settings.
Why IDS GV-53D1LE-MB Rev.2?
Because it delivers uncompromising clarity, speed, and reliability in a compact form. Powered by Sony’s IMX900 global shutter sensor, it captures every detail—whether you need rich color accuracy or razor-sharp monochrome precision—making it perfect for fast, high-stakes industrial applications.
What Problem Does It Solve?
It eliminates motion blur, poor contrast, and bulky camera integration issues in high-speed inspection and automation. With up to 73 fps, compact S-Mount design, and exceptional low-noise imaging, it transforms unreliable, slow visual checks into precise, repeatable, and fully automated quality control—boosting efficiency without sacrificing accuracy.
| Feature | Details | Benefit |
|---|---|---|
| Sensor Brand & Model | Color: Sony IMX900-AQR-C
Mono: Sony IMX900-AMR-C |
Proven Sony global shutter CMOS sensors deliver sharp, distortion-free imaging for fast-moving subjects. |
| Interface | GigE Vision (ZIF Connector) | Industry-standard connectivity for seamless system integration. |
| Interface Speed | 1 Gbps | High-speed data transfer over standard network infrastructure. |
| Resolution (HxV) | 2064 × 1552 (3.20 MP) | High detail for precise inspection and measurement. |
| Optical Area (HxV) | 4.644 mm × 3.492 mm | Maximizes light capture for improved image quality. |
| Optical Format | 1/3.1″ (Diagonal 5.81 mm) | Standard format ensures wide lens compatibility. |
| Lens Mount | S-Mount | Compact, lightweight lens options reduce overall system footprint. |
| Pixel Size | 2.25 µm | Captures fine details and enhances precision in small-object imaging. |
| Image Memory | Managed via IDS peak software | Efficient streaming without on-board storage bottlenecks. |
| Frame Rate @ Max. Resolution | Color: 37 fps (freerun) / 73 fps (triggered) / Mono: TBD (preliminary) | Supports high-speed imaging for time-critical processes. |
| Shutter | Global Shutter | Eliminates motion blur even with high-speed motion. |
| Exposure Time | Color: 0.016 ms – 2000 ms / Mono: TBD | Wide range for varied lighting conditions. |
| Trigger & Flash I/O | GPIO: 2 inputs, 1 trigger, 1 flash output | Enables precise synchronization with external lighting or motion control. |
| Power Supply | 12–24 V DC | Flexible integration into industrial power setups. |
| Software Tools | IDS peak software suite | Easy configuration, advanced image processing, and diagnostics. |
| Environmental Tolerance | Ambient: 0°C–25°C / Device: up to 80°C | Reliable operation in demanding industrial environments. |
| Housing Protection | Compact PCB/housing design | Ideal for embedded or space-limited applications. |
| Size & Weight | 50 × 50 × 23.5 mm, 27 g | Easy integration into robotic arms or tight enclosures. |
1. High-Speed PCB & Connector Inspection
The Sony IMX900’s 3.2 MP resolution with 2.25 µm pixels and a true global shutter captures tiny solder joints and lead edges without rolling-shutter distortion, even on fast conveyors. The compact 1/3.1″ format pairs well with S-Mount optics for short working distances in tight AOI stations. Low noise and fast readout enable precise defect detection on reflective copper or tin, while stable exposure timing supports dimensional checks and fiducial alignment for robotic pick-and-place. High frame rates help maintain takt time without sacrificing accuracy, transforming borderline manual checks into repeatable, automated inline measurements.
2. Robotic Pick-and-Place & AMR Perception
Compact cameras built on the IMX900 fit directly on robot wrists or mobile robot masts without exceeding payload limits. The global shutter freezes motion during moves, ensuring accurate part alignment and readable barcodes as robots navigate. The small optical format keeps lenses light, while the fine pixel pitch preserves edge sharpness for precise pose estimation. Fast exposure control and reliable triggering allow synchronization with strobed lighting to minimize blur and glare on glossy packaging. This makes it ideal for robot picking and autonomous mobile robots, reducing cycle times and mis-picks in mixed SKU environments.
3. Logistics Scanning, Sortation & Parcel Tracking
In high-speed logistics hubs, the IMX900’s global shutter prevents skewed codes and warped labels, improving first-pass read rates. High sensitivity and low dark current help maintain clarity in dim tunnels or enclosed scanner housings. Quick exposure adjustments stabilize brightness when parcel surfaces vary, and HDR modes manage shiny shrink-wrap or dark cardboard under mixed lighting. Combined with compact lenses, this sensor enables retrofitting small scan heads into crowded conveyor systems without major redesigns. The result is fewer no-reads, more accurate sortation, and improved throughput across distribution centers.
4. Intelligent Traffic Systems & License Plate Recognition
Traffic monitoring requires freezing vehicles moving at high speed and adapting to extreme lighting changes. The IMX900’s global shutter eliminates rolling distortion on moving plates, while its stacked BSI design sustains detail in compact optical setups. High frame rates, reliable triggering, and HDR capability help manage headlight glare, reflective plates, and nighttime conditions. The 3.2 MP format allows lane cropping or running multiple analytics, such as plate recognition, vehicle classification, and color detection, without enlarging the camera housing. This balance of speed, sensitivity, and size ensures accurate detection while keeping installation costs low.
5. Sports Analytics & High-Motion Event Capture
For ball tracking, finish-line timing, and player motion analysis, sharp imaging is critical. The IMX900’s global shutter and fast readout freeze motion precisely, enabling accurate timing and clean edge detection for rapidly moving objects. The 1/3.1″ sensor keeps the camera and lens package lightweight for use on rail cams or stabilizing gimbals, while the 2.25 µm pixel pitch preserves fine detail for model-based tracking. Consistent exposure and minimal distortion maintain reliable trajectory data and stable analytics across venues and varying lighting conditions, all without the need for bulky optics or heavy enclosures.
IDS Accessories (Recommended)
S-Mount Lenses (IDS Approved) – Optimized for 1/3.1″ sensors
GigE Hubs and Cables – For multi-camera synchronization setups
GPIO Interface Boards – To enable trigger/flash control with breakout access
12–24 V Industrial Power Adapters – Reliable power for continuous operation
Compact Mounting Brackets – For secure installation in tight spaces
IDS Imaging Cameras
GV-53D1LE-C-MB Rev.2 – 3.2 MP Color Global Shutter, Sony IMX900-AQR-C
GV-53D1LE-M-MB Rev.2 – 3.2 MP Mono Global Shutter, Sony IMX900-AMR-C
GV-51A2SE Series – 3.2 MP Sony IMX265 GigE Camera
U3-3271LE Series – 3.2 MP IMX265 in Compact USB3 Format
As an authorized distributor of IDS Imaging products, we offer certified expertise and technical support to ensure you get the most out of your IDS Imaging GV-53D1LE-MB Rev.2 camera. We stand by the quality of our products and provide comprehensive warranty services. Our team can also assist with special services like custom integration and creating pre-configured kits tailored to your specific needs.
We also offer:
Custom integration services for embedded systems
Pre-configured vision kits tailored to your project requirements
