GV-5580FA Rev.1.2 IDS Camera

~~$ 786.94~~
$ 708.25

Ethernet, CMOS, 15.0 fps, 2560 x 1920, 4.92 MPix, 1/2.5″, onsemi, Rolling Shutter

Product:
GV-5580FA-C-HQ Rev.1.2 (colour)

(Illustrations may differ from the original)

SKU N/A Category IDS FA Cameras

Interface

Camera Pixel, MPix

Camera Sensor Size

Camera Sensor Variant

Clear

IDS industrial camera or machine vision cameras was the most easy integration cameras in the market. Therefore is so easy for IDS cameras become most compatible with market most popular machine vision software such as OpenCV, Labview, Cognex and Halcon vision software. IDS also provide wide range of industrial C-mount cameras such GigE, 5 GigE, 10 GigE, USB 2.0, USB 3.0, and USB 3.1 interfacing models.

For find out more IDS Cameras please follow the link.

Meanwhile, if you need technical support please email us sales@inosaki.com

Camera Features

The GV-5580FA Rev.1.2 GigE Vision camera is equipped with the 4.92 megapixel CMOS sensor (MT9P006STC colour version) from onsemi. About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels. Thanks to the innovative A-Pix™ pixel technology, the sensor is very sensitive to light, which makes it an affordable alternative to many CCD sensors currently available on the market. This also makes the camera particularly suitable for applications that require maximum precision in colour rendering and crystal clear image quality.

The A-Pix™ pixel technology is based on the gathering of light by a lightguide, which directs the gathered incident light from the colour filter to the surface of the photo diode. Structure and process improvements in pixel technology have increased the sensitivity of the sensor in the red and green range in particular by up to 30 % compared to the previous version of the sensor.

Camera Data

Item number	AB12330
Name	GV-5580FA Rev.1.2
Camera family	FA
Interface	Ethernet
Interface-Speed	1.00 Gbps
Sensor type	CMOS
Sensor manufacturer	onsemi
Frame rate @ resolution max.	15.0 fps
Resolution (h x v)	2560 x 1920
Optical Area	5.632 mm x 4.224 mm
Shutter	Rolling Shutter
Optical class	1/2.5″
Resolution	4.92 MPix
Pixel size	2.20 µm
IP code	IP65/67
Product Life Cycle	Series
Sensor model	MT9P006
Data sheet	GV-5580FA-C-HQ Rev.1.2
