GV-51F0SE Rev.4.2 IDS Imaging
$ 1,244.30 – $ 1,259.25
$ 995.44 – $ 1,007.40
IDS imaging camera was the easiest integration cameras in the market. Therefore, is so easy for IDS cameras become most compatible with market most popular machine vision software such as OpenCV, Labview, Cognex and Halcon vision software. IDS also provide wide range of industrial C-mount cameras such GigE 5, GigE 10, GigE, USB 2.0, USB 3.0, and USB 3.1 interfacing models.
For find out more about IDS Imaging please follow the link.
Meanwhile, if you need technical support, please email us sales@inosaki.my
IDS Imaging Camera Features
The industrial camera GV-51F0SE Rev.4.2 features the 5.10 MPix global shutter sensor IMX547 from the Sony Pregius S series. As a fourth generation sensor (1/1.8″, 2472 x 2064 px), it not only possesses BSI (Backside Illumination) technology, but also a remarkably small pixel size of just 2.74 µm. This means that users benefit from exceptional pixel density and particularly good image quality – even in changing light conditions. In operation, the industrial camera delivers 24.0 fps. Thanks to these features and various housing versions – from board-level versions to completely closed – the industrial camera can be used for a wide range of tasks.
Thanks to its GigE Vision interface, the industrial camera is uncompromisingly standard-compliant and can therefore be used conveniently with our IDS peak SDK.
The uEye+ SE camera is available as a monochrome or colour version.
Camera Data
Item number |
|
Camera family | SE |
Interface | Ethernet |
Interface-Speed | 1.00 Gbps |
Sensor type | CMOS |
Sensor manufacturer | Sony |
Frame rate @ resolution max. | 24.0 fps |
Resolution (h x v) | 2472 x 2064 |
Optical Area | 6.773 mm x 5.655 mm |
Shutter | Global Shutter |
Optical class | 1/1.8″ |
Resolution | 5.10 MPix |
Pixel size | 2.74 µm |
IP code | IP30 |
Product Life Cycle | Series |
Sensor model | IMX547 |
Data sheet |
Weight | N/A |
---|---|
Dimensions | N/A |
Camera Interface | Ethernet |
Camera Pixel | 5.1 |
Camera Sensor Size | 1/1.8'' |
Camera Sensor Variant | Colour, Monochrome |
