1. Pneumatic Control Panels in Cleanroom Packaging Lines
Using its certified ISO Class 4 cleanroom suitability and VDMA24364 zone III (LABS/PWIS conformity), this fitting is deployed in medical device or electronic components packaging lines. It facilitates the distribution of dry compressed air through 6 mm tubing, ensuring zero paint-wetting impairment.
Problem SolvedPrevents contamination of products and packaging equipment from outgassing or particle emissions, which would otherwise ruin sensitive components or paint-adhesiveness on packaging.
Cleanroom ISO Class 4VDMA24364 zone IIIPneumatic Distribution6 mm Tubing
2. End-of-Arm Tooling (EOAT) in Pick-and-Place Systems
The lightweight straight design (23.17g) and standard 6 mm OD connection allow direct integration onto robot arms or pick-and-place end effectors operating within -0.95 to 8 bar vacuum/pressure. The push-pull principle allows rapid replacement of tubing during preventative maintenance.
Problem SolvedReduces payload drag and avoids bulky setups on robotic joints while providing a secure lock via the stainless steel retaining claw to withstand high acceleration forces.
Push-pull principleStainless steel retaining clawPick-and-placeVacuum and Pressure
3. Industrial Manifold Compressed Air Distribution
Screwed into manifolds with R3/8 female threads, this fitting routes main supply lines down to individual 6mm pneumatic actuators. The pre-coated PTFE sealant on the tapered R3/8 thread enables fast, leak-free assembly directly onto manifolds without using liquid sealants or Teflon tape.
Problem SolvedEliminates the risk of excess tape or paste debris entering and damaging downstream pneumatic valves or cylinders during manifold assembly.
R3/8 ThreadPTFE Thread CoatingPneumatic ManifoldLeak-free Assembly
