E30S4-360-6-L-5-30 mm Incremental Rotary Encoders (Shaft Type) – Autonics

$ 74.06

Autonics

Features

  • Shaft outer diameter : Ø4mm
  • Max. response frequency : 300kHz
  • Max. allowable revolution : 5000rpm
  • Starting torque : Max. 20gf.cm(max. 0.00196N.m)
  • Resolution : 360P/R
  • Control output : Line Driver
  • Power supply : 5VDC  ±5%(ripple P-P: max. 5%)
  • Connection type : Axial cable type
  • Protection structure : IP50

Specifications

Data sheet

Shaft outer diameter Ø4mm
Max. response frequency 300kHz
Max. allowable revolution 5000rpm
Starting torque Max. 20gf.cm(max. 0.00196N.m)
Resolution 360P/R
Output phase A, , B, , Z,
Control output Line Driver
Power supply 5VDC  ±5%(ripple P-P: max. 5%)
Connection type Axial cable type
Protection structure IP50
Environment_Ambient temperature -10 to 70℃, storage: -25 to 85℃
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 90% RH
Accessories Ø4mm coupling
Weight Approx. 80g
